800B Series
800B Series Sealed, Subminiature SMT Pushbutton Switches
SMT surface mount subminiature pushbutton switches featuring SPST or SPDT functions, tape and reel packaging, and 3A ratings.
-
900 Series
900 Series Subminiature, Right Angle Detector Switch
Subminiature surface mount detector switch with low operating force and right angle actuation. Silver contacts. Tape and reel packaging.
-
CS Series
CS Series Illuminated, Touch Sensor Anti-Vandal Switch
The CS Series illuminated, anti-vandal switch provides capacitive switch technology, also known as a touch sensor, and can perform momentary or latching functions. It is meant for panel cutouts sized 19mm or 22mm.
-
E100 Series
E100 Series Pushbutton Switch
The E100 Series pushbutton switch is an easy to operate emergency stop (E-Stop) with an eye-catching red actuator and multiple illumination options.
-
E200 Series
E200 Series Pushbutton Switch
The E200 Series pushbutton switch is an easy to operate emergency stop (E-Stop) with an eye-catching red actuator and multiple illumination options.
-
FS5700 Series
FS5700 Series Pushbutton Foot Switch
The FS5700 Series foot-actuated pushbutton switch is available with SPDT, DPDT, or 3PDT circuits for performing momentary or alternate action functions. It has high actuation force and PC board mount or panel mount designs.
-
JS1300 Series
JS1300 Series 5-Position Navigation Switch
The JS1300 Series 5-position navigation switch has north, south, east, west, and center actuation with a very low profile and sleek design for surface mounting.
-
JS1400 Series
JS1400 Series 5-Position, Joystick Navigation Switch
The JS1400 5-position, joystick navigation switch is surface mountable and features a long mechanical life expectancy of 100,000 cycles. Three different actuator options are also available.
-
KAE Series
KAE Series Low Profile DIP Switch
The KAE Series is a low profile DIP switch for surface mounting or PC board mounting via through hole (straight or splayed) termination. Features up to 12 positions and your choice of tube or tape and reel packaging with an optional top seal.
-
KAN Series
KAN Series Half Pitch, Low Profile DIP Switch
The KAN Series half pitch, low profile DIP switch is surface mountable, has an optional top seal, and comes in tube or tape and reel packaging. Recessed actuator positions include 2, 4, 6, 8, and 10.
-
KC Series
KC Series Rotary Switch
These rotary switches offer many different models including SP, DP, 3P and 4P. Some models come with stops, others no stops. Up to 12 positions. PCB pin or solder lug termination options and many different actuator lengths.
-
KC1901 Series
KC1901 Series Rotary Switch
The KC1901 Series rotary switch offers up to 9 positions in a through-hole mounting design.
-
KS1100 Series
KS1100 Series Pushbutton Switch with Keyboard Functionality
The KS1100 Series pushbutton switch offers keyboard functionality. With a 10mA, 12VDC rating, it is a single pole, single throw (SPST) switch with momentary function and a tall actuator height of 15.2mm.
-
LB22 Series
LB22 Series Illuminated Pushbutton Switch
The LB22 Series is a pushbutton available with or without illumination and sealed at an IP65 ingress protection rating. Single- or double-pole functions and latching or momentary options are available, as are multiple colors and illumination voltage.
-
LC Series
LC Series Pushbutton Switch
These pushbutton switches can perform a momentary or maintained (latching) function, with a through hole mounting design and a right angle mounting option. They are also offered in shorting or non-shorting versions.
-
LP11 Series
LP11 Series Illuminated Pushbutton Switch
The LP11 Series illuminated pushbutton switch offers multiple cap and LED color options, momentary or latching functions, and comes with or without a tactile response.
-
LP6 Series
LP6 Series Illuminated Pushbutton with Multiple LED Color Options
This illuminated pushbutton switch offers one or two poles, full LED illumination, and a vertical through hole mount. Also offered are RGB color options.
-
LS Series
LS Series Long Life Snap Action Switch
These standard-sized, snap action switches offer up to 1 million life cycles and have multiple actuator and termination options.
-
MR1000 Series
MR1000 Series Detector Switch
The MR1000 Series is a recessed magnetic or reed type switch which comes in a two-piece design. One piece contains the magnet and the other piece contains the reed switch.
-
MS Series
MS Series Miniature Snap Action Switch
Many operating force, actuator, and termination options are available with this miniature snap action switch. Operating life of up to 1 million cycles, and up to 5A with UL power rating and gold contacts.
-
PA4 Series
PA4 Series Illuminated, Power Pushbutton Switch
The PA4 Series pushbutton has high power ratings, offers both standard and water resistant versions, and features full illumination options with multiple lens colors.
-
PB300 Series
PB300 Series Long Travel Pushbutton Switch
Choose between a single pole, single throw (SPST) momentary pushbutton switch or a single pole, double throw (SPDT), double action switch, which actuates mid-travel, and then again at full travel.
-
PB350 Series
PB350 Series Pushbutton Switch
PB350 Series pushbuttons feature SPST or SPDT/Double action functions, long travel, gold contacts and five LED options.
-
PB66 Series
PB66 Series Illuminated Pushbutton Switch
The PB66 Series pushbutton switch is rated IP66 for dust and moisture protection, features a 50,000-cycle electrical life expectancy, and comes illuminated or non-illuminated.
-
PMV6 Series
PMV6 Series Anti-Vandal Switch
Our PMV6 Series anti-vandal pushbutton switches come with your choice of multiple function options and cap colors. This IP67-rated switch offers a 10,000-cycle electrical life, an operating temperature range of -20°C to 65°C, and fits a panel cutout sized 16mm.
-
PP1 Series
PP1 Series Push-Pull Pushbutton Detector Switch
These are detector or door interlock switches and are available as push-pull or momentary pushbuttons. They have high UL power ratings of 16A.
-
PP2 Series
PP2 Series Push-Pull Pushbutton Detector Switch
The PP2 Series pushbutton switch acts as a door interlock or detector switch, is available as a push-pull or momentary pushbutton and is UL power rated.
-
PV0 Series
PV0 Series Sealed, Illuminated Anti-Vandal Switch
The PV0 Series anti-vandal switch is rated IP67 for protection against dust and moisture and is illuminated, with multiple color options. It fits a 12mm panel cutout with a maximum depth of 6mm.
-
PV1 Series
PV1 Series Long Life, Water Resistant Anti-Vandal Switch
The PV1 Series water resistant, sealed anti-vandal switch features long life and custom laser engraved marking options. It has a panel cutout size of 19mm (8mm max. depth) and is sealed to an IP65 rating.
-
PV10 Series
PV10 Series Illuminated Anti-Vandal Switch
The PV10 Series illuminated anti-vandal switch is rated IP65 for dust and moisture protection and has a mechanical life of a million cycles. It fits a panel cutout 40mm in diameter with a maximum depth of 5mm.
-
PV2 Series
PV2 Series Sealed, Long Life Anti-Vandal Switch
Dust and water resistant to IP65, this anti-vandal switch has a long life expectancy and a panel cutout size of 16mm (6mm max. depth). It offers an Off-(On) configuration and your choice of domed, flat, or high actuator options.
-
PV3 Series
PV3 Series Illuminated, Sealed, Long Life Anti-Vandal Switch
These anti-vandal switches have dot and ring illumination options, 1- or 2-pole circuits performing momentary functions and are available with either IP40 (non-water resistant) or IP67 (water resistant) ratings. They fit in a panel cutout sized 16mm, with a maximum depth of 8mm.
-
PV4 Series
PV4 Series Illuminated, Long Life, Sealed Anti-Vandal Switch
This switch offers dot and ring illumination options, 1 or 2 poles for performing maintained and momentary functions and double break functions, with an IP65 rating for dust and water resistance. It is meant for a panel cutout sized 19mm, with a maximum depth of 11mm.
-
PV6 Series
PV6 Series Illuminated, Sealed, Long Life Anti-Vandal Switch
These long life anti-vandal switches have an IP65 rating for protection against dust and moisture, dot and ring illumination options, and have solder lug or wire lead terminal options. They are meant for a panel cutout 16mm in size with a maximum depth of 10mm.
-
PV7 Series
PV7 Series Illuminated, Sealed Anti-Vandal Switch
These pushbutton switches have a 22mm diameter panel cutout, dot and ring illumination options, 1-pole, double break function and are IP65 rated.
-
PV8 Series
PV8 Series Illuminated, Sealed Anti-Vandal Switch
These switches are meant for a panel cutout 25mm in diameter, feature dot and ring illumination, 1 or 2 poles, maintained and momentary, double-break functions, and are IP65 rated.
-
PV9 Series
PV9 Series Sealed, Illuminated Anti-Vandal Switch
The PV9 Series anti-vandal switch offers a 28mm diameter cutout size with an IP66 rating for dust and moisture protection, and dot or ring illumination.
-
PVA3 Series
PVA3 Series Illuminated Anti-Vandal Switch
The PVA3 Series anti-vandal switch provides ring illumination with multiple LED color options. It is IP65 rated and performs momentary or latching functions. This switch is meant for a panel cutout sized 16mm in diameter with a maximum depth of 8mm.
-
PVA6 Series
PVA6 Series Illuminated, Long Life Anti-Vandal Switch
The PVA6 Series illuminated anti-vandal switch offers a long life expectancy, dust and water resistance to an IP67 rating, and ring or power symbol illumination. It fits a panel cutout sized 16mm in diameter with a maximum depth of 6-8mm.
-
PVB3 Series
PVB3 Series Anti-Vandal Switch
The PVB3 Series is an anti-vandal switch with an IP65 rating, 16mm panel cutout, momentary or latching functions and multiple LED color options for ring or power symbol illumination.
-
PVHC4 Series
PVHC4 Series Anti-Vandal Switch
The PVHC4 Series is a high-current anti-vandal switch rated for 20A, 250VAC and 25A, 30VDC. It fits a 19mm diameter panel cutout, has an IP67 rating and features multiple LED options.
-
PVK4 Series
PVK4 Series Illuminated Anti-Vandal Switch
The PVK4 Series is an anti-vandal switch (19mm panel cutout) rated IP65 for dust and moisture protection with a keylock option rated IP40. Multiple illumination colors and voltages are also available.
-
PVL Series
PVL Series Sealed Pilot Lamp Indicator
IP67 sealed lamp indicator switch with multiple panel cutout sizes ranging from 6mm to 19mm in diameter.
-
PVP Series
PVP Series Anti-Vandal Switch Socket
The PVP Series anti-vandal switch socket offers quick, efficient termination. It is available with solder lugs or can be direct wired. The PVP socket with solder lugs is for anti-vandal series PV3, PV4, PV7. Direct wired sockets are available for anti-vandal series PV3, PV4, PV7, PV8, PV9, and PV10.
-
PVS7 Series
PVS7 Series Illuminated Anti-Vandal Switch
This switch offers ring illumination, single-pole or double-pole circuits, stainless steel housing material, and many LED illumination options, including RGB. It is meant for a panel cutout 22mm in diameter.
-
PVT4 Series
PVT4 Series Illuminated, Tactile Response Anti-Vandal Switch
This switch offers a 19mm diameter panel cutout, dot and ring illumination options, crisp tactile response, momentary functionality with an IP65 rating.
-
PZ Series
PZ Series Anti-Vandal, Illuminated Piezo Switch
The PZ Series is an anti-vandal, panel mount (16, 19 or 22mm cutout), piezo switch with momentary pulse functionality and 50 million cycles of electrical life. The PZ Series is offered as non-illuminated or ring pattern illumination with LED RGB.
-
R5 Series
R5 Series Illuminated, High Current Rocker Switch
These high current rocker switches offer full illumination options with customizable actuators in a snap in panel cutout sized 22mm by 30mm. Electrical rating of 20 amps.
-
RA8 Series
RA8 Series Illuminated, Power Rocker Switch
The RA8 Series power rocker switch has a high electrical rating of up to 16 amps. The RA8 offers full or signal light illumination with multiple LED lens colors and an optional cap for protection from dust and moisture at an IP54 rating. It fits a panel cutout 13mm by 19mm in size.
-
RB1 Series
RB1 Series Illuminated, Power Rocker Switch
The RB1 Series power rocker switch has a high electrical rating of up to 20 amps and features multiple terminal, actuator, and illumination options, plus an optional cap for dust and moisture protection at an IP54 rating. It fits a panel cutout sized 11mm by 30mm.
-
RB2 Series
RB2 Series High Current, Power Rocker Switch
The RB2 Series illuminated, power rocker switch is electrically rated for 20 amps and has an optional cap for dust and water protection at an IP54 rating. Dot, full, signal light, or non-illumination options are available for this switch meant for a 22mm by 30mm panel cutout.
-
RBW2 Series
RBW2 Series Illuminated, Sealed Rocker Switch
The RBW2 Series illuminated rocker switch is sealed to IP66 ratings without requiring a rubber boot. UL approved to 1/3 HP and [cURus] approved for up to 16 amps. Fits panel cutout sized 22mm by 30mm.
-
RD1 Series
RD1 Series Compact, Power Rocker Switch
The RD1 Series compact, power rocker switch is a small rocker switch with high electrical ratings. It is ideal for applications with limited space. Rated for up to 16A and 1/3HP, this switch fits a panel cutout 6.8mm by 19.2mm in size.
-
RE1 Series
RE1 Series Oval, Illuminated Power Rocker Switch
The RE1 Series illuminated power rocker switch features a unique oval shape and high electrical ratings with [UL] and [cURus] approvals. There are multiple actuator marking options and lens colors available. It fits an oval panel cutout 13.5mm by 23.3mm in size.
-
RP3508 Series
RP3508 Series Round, Illuminated Pushbutton Switch
The RP3508 Series illuminated pushbutton is a round, panel mount switch that comes with green, red or yellow LED options.
-
RP8100 Series
RP8100 Series Round, Illuminated Pushbutton Switch
The RP8100 Series pushbutton switch comes in a sleek, round design, you can get it in a threaded or snap-in panel mount version. There are 5 LED color options.
-
RP8200 Series
RP8200 Series Illuminated, Round Pushbutton Switch
Affordable, maintained, sealed pushbutton switch that is panel mounted with options to illuminate. This slick design offers threaded panel mounting with multiple actuator color options.
-
RP8300 Series
RP8300 Series Round, Illuminated Pushbutton Switch
This panel mount switch is a SPST, momentary pushbutton with a long life expectancy and is sealed at an IP65 rating. It\'s an illuminated pushbutton with multiple LED and cap color options.
-
RP8400 Series
RP8400 Series Square, Illuminated Pushbutton Switch
The RP8400 Series switches are square, momentary pushbuttons sealed to an IP65 rating with a die cast housing and nylon actuator. The illuminated pushbutton comes in many colors.
-
RP8500 Series
RP8500 Series Square Illuminated Panel Mount Pushbutton Switch
This pushbutton switch has a 13.6mm diameter panel cutout and is an SPST momentary (500,000 life cycles) switch. It is IP65 sealed, and has a nylon housing & actuator.
-
RP8600 Series
RP8600 Series Square, Sealed Pushbutton Switch
The RP8600 Series square, sealed pushbutton switches are protected from moisture at an IP67 rating and have a mechanical life expectancy of 100,000 cycles.
-
RR1 Series
RR1 Series Round, Illuminated Power Rocker Switch with Cap
The RR1 Series is an aesthetically designed power rocker switch with a round body and full illumination. It is a single-pole rocker switch with many functions and comes with a cap for protection against dust and moisture at an IP54 rating. It fits a panel cutout 20mm in size.
-
RR3112 Series
RR3112 Series Round, Illuminated Power Rocker Switch
This round, illuminated power rocker switch has an electrical rating up to 16 amps, features full illumination, and has an ergonomic feel that is also visually pleasing. It fits a panel cutout 20.2mm in size.
-
RR5 Series
RR5 Series Round, High Current Rocker Switch
The RR5 Series round rocker switch is aesthetically designed and has high electrical ratings with UL and cURus approvals. It has single-pole circuits for performing various functions and a short body for low clearance applications. It\'s meant for a panel cutout 20mm in diameter.
-
RRG3 Series
RRG3 Series Round, Power Rocker Switch
The RRG3 Series round, power rocker switch has a glossy finish and high electrical ratings up to 16 amps. It is aesthetically designed with single-pole functionality and is UL listed. It fits a panel cutout 20mm in diameter.
-
RSC Series
RSC Series High Current Rocker Switch with Bi-color Actuator
The RSC Series illuminated, power rocker switch has a bi-color actuator and four sizes to cover many popular cutouts. High electric current capacity of up to 20 amps and 1/4 HP rating.
-
RVW Series
RVW Series High Current Power Rocker Switch
The RVW Series high current rocker switch features an internal dust and water protection seal rated IP54. Glossy finish and multiple marking options and switch functions are available for this switch that fits a panel cutout sized 21mm by 36.8mm.
-
SAV8 Series
SAV8 Series Anti-Vandal Switch
The SAV8 Series anti-vandal switch offers multiple illumination options and is sealed to an IP67 rating. It fits a 25mm round panel cutout.
-
SS Series
SS Series Subminiature, Snap Action Switch
The SS Series subminiature, snap action switches are designed for higher reliability applications. They have an operating life up to 1 million cycles and feature multiple actuator and termination options.
-
ST2 Series
ST2 Series High Current, Power Toggle Switch
The ST2 Series power toggle switches have a heavy duty rating with agency approvals to handle up to 20 amps. Tab, screw, solder and wire lead terminal options are available.
-
ST3 Series
ST3 Series High Current, Power Toggle Switch
The ST3 Series power toggle switch offers a heavy duty rating with agency approvals for handling up to 24 amps. It has tab, screw, solder, or wire lead terminal options.
-
ST4 Series
ST4 Series Sealed Toggle Switch
The ST4 Series sealed toggle switches are rated IP68 for dust and moisture protection and offer single pole or double pole circuit functions with 2 or 3 actuator positions. Select from 10 different function options, three electrical rating options, and 17mm metal or 22mm plastic bat actuator.
-
ST5 Series
ST5 Series High Temperature Toggle Switch
The ST5 series toggle switch series can handle temperatures ranging from -10°C to 125°C. The ST5 offers a single pole or double pole circuit function with two or three positions and offers three electrical rating options.
-
SV7 Series
SV7 Series Short Body Anti-Vandal Switch
The SV7 Series is a short body anti-vandal switch rated IP67 for protection against dust and moisture. It has a 22mm diameter panel cutout size. This illuminated switch is available with solder terminals or wire leads.
-
SV8 Series
SV8 Series Short Body Anti-Vandal Switch
The SV8 Series is an IP67 rated, short body, illuminated anti-vandal switch. It is meant for a 25mm panel cutout, making it the largest of the SV Series switches.
-
TD1146 Series
TD1146 Series SMT Ultraminiature Detector Switch
The TD1146 Series detector switch is ultraminiature in size with a 4.8mm x 3.5mm footprint and requires less than 50 grams of force to actuate.
-
TD1150 Series
TD1150 Series Sealed Detector Switch
The TD1150 is a thru hole PCB mounted detector switch. It is IP65 rated for dust and moisture protection and provides full travel around 2.5mm with the electrical make around .5mm’s. Actuation force to the electrical make is only 35 grams.
-
TD1250 Series
TD1250 Series Long Life, Sealed Detector Switch
The TD1250 Series detector switches feature a 500,000-cycle mechanical life at minimum and are rated IP67 for dust and moisture protection. They come with mounting bosses and have three actuator options.
-
TD4700 Series
TD4700 Series Ultraminiature Detector Switch
Ultraminiature surface mount detector switch with a very low profile and a guiding post for easy orientation.
-
TL1030 Series
TL1030 Series Tact Switch
The TL1030 Series is a surface mount tact switch measuring 3.5 x 2.9mm with multiple actuation force options.
-
TL1100 Series
TL1100 Series Tactile Switch
The TL1100 Series is a 12mm x 12mm tactile switch with vertical and right angle mounting designs, and silver or gold plated contacts.
-
TL1105 and TLE1105 Series
TL1105 and TLE1105 Series Tactile Switches
The TL1105 and TLE1105 Series are 6mm x 6mm tactile switches come with a right angle option, many actuator lengths, and multiple operating forces.
-
TL2233 Series
TL2233 Series Subminiature Pushbutton Switch
The TL2233 Series subminiature switch is a surface mountable (SMT), momentary contact push button with a DPDT contact arrangement and gull wing terminals that are wave solderable. The switch has a long electrical life of 10,000 cycles.
-
TL3301 Series
TL3301 Series SMT Tactile Switch
The TL3301 Series is a 6mm x 6mm SMT tact switch. Designed for SMT applications, the TL3301 offers several actuator heights, multiple operating force, gold or silver plated contacts.
-
TL52 Series
TL52 Series Sealed, Radial Lead Tactile Switch
The TL52 series tactile switch is a thru hole switch that comes in radial packaging and is a sealed switch with IP67 rating.
-
TS Series
TS Series Subminiature, Snap Action Switch
The TS Series subminiature, snap action switch comes with a vertical, left angle, or right angle PCB pin termination in two different lengths.
-
TS2 Series
TS2 Series Surface Mount, Snap Action Switch
The TS2 Series surface mount, snap action switch has a subminiature package size and is designed for higher reliability applications, with a life expectancy of 3 million cycles.
-
ULV4 Series
ULV4 Series UL Certified, Long Life Anti-Vandal Switch
This anti-vandal switch with UL certification is rated to 3 amps with various illumination options, IP67 protection from dust and moisture, and a mechanical life of up to one million cycles. It fits a panel cutout 19mm in diameter with a maximum depth of 10mm.
-
ULV7 Series
ULV7 Series UL Certified Anti-Vandal Switch
The ULV7 Series is a tamper resistant switch that is UL Listed and IP67 rated for dust and moisture protection. It fits a 22mm round panel cutout with a maximum depth of 10mm.
-
ULV8 Series
ULV8 Series UL Certified, Sealed Anti-Vandal Switch
The ULV8 Series anti-vandal switch is UL certified and rated IP67 for dust and moisture protection. It fits a panel cutout 25mm in diameter with a maximum depth of 10mm.
-
WB2 Series
WB2 Series Sealed, High Current Rocker Switch
The WB2 Series high current rocker switch has an internal dust and water protection seal rated IP55. It handles up to 20 amps and comes with 2-pole circuits for performing various functions. It fits a panel cutout sized 22mm by 30mm.
-
WS Series
WS Series Sealed, Snap Action Switch
This snap action switch is sealed to an IP67 ingress protection rating for dust and moisture and offers multiple termination options including wire leads.
-
WS1 Series
WS1 Series Sealed, Snap Action Switch
The WS1 Series is a panel mount, snap action switch sealed to an IP67 rating for dust and moisture protection with SPDT On-(On) function, multiple electrical ratings, pin plunger actuator, and solder lug or 162mm long wire lead termination.
-
WS2 Series
WS2 Series Sealed, Snap Action Switch
The WS2 Series snap action switch is rated IP67 for dust and moisture protection, handles up to 2 amps, has a long life expectancy, and comes with multiple terminal options.
