RA1 Series Illuminated, Power Rocker Switch with PVC Cap

RA1 Series Illuminated, Power Rocker Switch with PVC Cap

The RA1 Series illuminated, power rocker switch has a high electrical rating of 16 amps and snap in with nine terminal options. The PVC cap provides protection from water and dust at an IP54 rating, and the curved actuators are available in many colors with various marking options, making these custom rocker switches. The RA1 Series illuminated power rocker switch has an electrical rating of up to 16 amps with a cURus agency approval. Full illumination and signal light illumination options are available in various LED lamp voltages and with five lens colors. This LED rocker switch is meant for a panel mount cutout sized 13mm x 19.2mm. Applications for the RA1 Series power rocker switch include but are not limited to:

  • Marine
  • Transportation
  • Industrial


  • Up to 16A, 125VAC electrical rating
  • PVC cap provides protection from dust and moisture at IP54 rating
  • 13mm x 19.2mm panel cutout
  • Full or signal light illumination options

RA1 Series Illuminated, Power Rocker Switch with PVC Cap

decoration Ra1 Wire

Industry Utilization:



Series Configurator

* If you need further customization let us know and we'll see how we can help!

Product Number:

Ra1 Wire

* Product image not available for this configuration.

Displaying general product image that doesn't necessarily match configuration.

Detail Specifications

ELECTRICAL RATING: Rating Option 3: 10A @ 125VAC [cULus]; Rating Option C: 16A @ 125VAC, 1/3HP [cULus]; 10A @ 250VAC, 1/3HP [cULus] OPERATING/STORAGE TEMPERATURE: -20°C to 105°C ELECTRICAL LIFE: 10,000 Cycles CONTACT RESISTANCE: 30mΩ Max. INSULATION RESISTANCE: 500MΩ Min. at 500VDC DIELECTRIC STRENGTH: 1,000VAC for 1 Minute DUST/MOISTURE PROTECTION: IP54 with PVC Cap
