PV16 Series

PV16 Series Illuminated Anti-Vandal Switch

• 16mm panel cutout
• 2A, 24VDC / 5A, 220VAC;  IP67
• SPDT or DPDT
• High or flat actuator
• Solder, wire leads, or w/ connector
• LED ring, dot, or ring/power symbol
• Stainless steel or black anodized

View Series

TD1350 Series

TD1350 Series Pushbutton Detector Switch

• 14.5mm diameter cutout; Snap-In
• Up to 12A, 125/250VAC; UL, ENEC
• SPST Off-(On)
• Pin plunger actuator
• Quick connect or solder lug
• Black or white body and actuator
• Acts as door interlock or detector

View Series

TL6059 Series

TL6059 Series Sealed, Through Hole, Radial Lead Tactile Switch

• IP67 rated
• Through hole
• 6.00mm x 6.00mm
• PC Pin termination
• Actuator height options
• 100gf, 160gf, or 200gf
• Radial lead packaging

View Series

TL3220 Series

TL3220 Series Ultraminiature, RGB Illuminated, SMT Tactile Switch

• SMT
• 4.90mm x 4.90mm
• Gull wing termination
• LED, RGB illuminated
• 160g operating force
• Gold contact material
• 50mA @ 12VDC

View Series

LS25 Series

LS25 Series High Current Snap Action Switch

• Chassis mount
• High Current snap action switch
• Silver – 25A, 125/250VAC; UL
• SPDT; On-(Off)
• Solder or quick connect
• Pin plunger, or six lever options
• 90gf – 400gf operating force

View Series

TS1 Series

TS1 Series Subminiature Snap Action Switch

• Through hole
• 100mA, 125VAC or 48VDC
• PC Pin termination
• SPST Off-(On)
• Pin plunger actuator
• 70gf operating force
• Silver contact material

View Series

RP8700 Series

RP8700 Series Round, Illuminated Pushbutton Switch

• 13.6mm panel cutout
• 200mA, 50VDC;  IP68
• SPST; Off-(On) or On-(Off)
• Solder, PCB, or wires w/ connector
• Round button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

View Series

RA2 Series

RA2 Series Dual Power Rocker Switch with PVC Cap

• 22mm x 19.2mm panel cutout
• Dual rocker switch
• Up to 16A, 250VAC; UL
• SPST or SPDT; latching or mom.
• Quick-connect, solder, or wires
• Actuator marking options
• IP54 with PVC cap:  ACC-P02

View Series

RCA1913 Series

RCA1913 Series Sealed, Power Rocker Switch

• 19.2mm x 13mm panel cutout
• Up to 16A, 125VAC; UL;  IP68*
• SPST or SPDT; latching function
• QC-tabs, solder, PC pin, or wires
• Housing and actuator color options
• Actuator marking options
• Right angle mounting option

View Series

PR1 Series

PR1 Series Illuminated, Power Pushbutton Switch with PVC Cap

• 25mm panel cutout;  Snap-In
• 16A, 125VAC; UL
• SPST or DPST; latching or mom.
• Quick connect termination
• Round actuator; color options
• Illumination & marking options
• IP54 with PVC Cap: ACC-F03

View Series

RP3502 Series

RP3502 Series Pushbutton Switch

• 12.7mm panel cutout
• 3A, 120VAC; UL
• SPST; Off-(On) or On-(Off)
• Plastic or metal body style
• Solder termination
• Round button actuator
• Actuator color options

View Series

RRS20 Series

RRS20 Series Round, Sealed, Illuminated, Power Rocker Switch

• 20mm diameter panel cutout
• Up to 16A, 250VAC; UL;  IP68
• SPST or SPDT; latching function
• Quick connect, solder or wire leads
• LED illumination options
• Actuator color options
• Actuator marking options

View Series

R4 Series

R4 Series Illuminated, Power Rocker Switch

• 30mm x 11mm panel cutout
• Up to 20A, 125VAC; UL
• SPST or SPDT; latching or mom.
• Quick connect, or wire leads
• Housing and actuator color options
• LED or Neon illumination options
• Actuator marking options

View Series

R1973 Series

R1973 Series Illuminated, Power Rocker Switch

• 19.2mm x 13mm panel cutout
• 9A, 125VAC; UL
• SPST or DPST; latching or mom.
• QC-tabs, PC pin, or wire leads
• Housing and actuator color options
• LED or Neon illumination options
• Actuator marking options

View Series

R1966 Series

R1966 Series Illuminated, Power Rocker Switch

• 19.2mm x 13mm panel cutout
• 15A, 125VAC; UL
• SPST or SPDT; latching or mom.
• QC-tabs, solder, PC pin, or wires
• Housing and actuator color options
• LED illumination options
• Actuator marking options

View Series

400U Series

400U Series Ultraminiature Rocker Switch

• Through hole
• Gold – 0.4VA, 20V max. (AC or DC)
• DPDT On-On
• Straight, rt. angle, or rt. angle vert.
• Rocker or paddle actuator
• Actuator color options
• Epoxy sealed terminals

View Series

400B Series

400B Series Sealed, Subminiature, SMT Right Angle Rocker Switch

• SMT right angle;  IP67
• Silver – 3A, 120VAC or 28VDC; UL
• Gold – 0.4VA, 20V max. (AC or DC)
• SPDT; latching or momentary
• Standard, black rocker actuator
• Epoxy sealed terminals
• Tape & reel packaged

View Series

400A Series

400A Series Sealed, Subminiature Rocker Switch

• Panel mount or through hole;  IP67
• Silver – 3A, 120VAC or 28VDC; UL
• Gold – 0.4VA, 20V max. (AC or DC)
• SPDT or DPDT; latching or mom.
• Straight, rt. angle, or rt. angle vert.
• PC Pin or Solder termination
• Actuator color options

View Series

400 Series

400 Series Subminiature Rocker Switch

• Panel mount or through hole
• Silver – 3A, 120VAC or 28VDC; UL
• Gold – 0.4VA, 20V max. (AC or DC)
• SPDT, DPDT, or SPST; latch. or mom.
• Straight, rt. angle, or rt. angle vert.
• PC Pin or Solder termination
• Actuator color options

View Series

ULP Series

ULP Series Illuminated Pushbutton Switch

• Through hole or panel mount
• 500mA, 25VDC (Silver)
• 100mA, 28VDC (Gold)
• SPDT or DPDT; latching or mom.
• PC pin or solder termination
• Variety of cap styles; clear diffuser
• LED illumination options

View Series

TL2233 Series

TL2233 Series Subminiature Pushbutton Switch

• SMT
• 100mA, 30VDC
• Non-Shorting – BBM
• DPDT On-(On)
• Gull wing termination
• Rectangular button actuator
• 250gf operating force

View Series

RP8600 Series

RP8600 Series Square Pushbutton Switch

• 16mm panel cutout
• 0.4VA, 20V max. (AC or DC);  IP67
• SPST Off-(On)
• Solder termination
• Square bezel; round button flush
• Threaded bushing: M16 x 1.0
• Gold over silver contact material

View Series

RP8500 Series

RP8500 Series Square, Illuminated Pushbutton Switch

• 13.6mm panel cutout
• 100mA, 50VDC;  IP67
• SPST Off-(On)
• Solder termination
• Square button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

View Series

RP8400 Series

RP8400 Series Square, Illuminated Pushbutton Switch

• 13.6mm panel cutout
• 200mA, 50VDC;  IP67
• SPST Off-(On)
• Solder termination
• Square button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

View Series

RP8300 Series

RP8300 Series Round, Illuminated Pushbutton Switch

• 13.6mm panel cutout
• 200mA, 50VDC;  IP67
• SPST Off-(On)
• Solder termination
• Round button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

View Series

RP8200 Series

RP8200 Series Round, Illuminated Pushbutton Switch

• 13.6mm panel cutout
• 100mA, 24VDC;  IP67
• SPST Off-On
• Solder termination
• Round button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

View Series

RP8100 Series

RP8100 Series Round, Illuminated Pushbutton Switch

• 13.6mm panel cutout
• 100mA, 24VDC; IP67
• SPST; Off-(On)
• Solder or wire leads termination
• Round button, many color options
• Snap-in or threaded (M12 x 0.75)
• LED illumination options

View Series

RP3508 Series

RP3508 Series Illuminated Pushbutton Switch

• 16mm panel cutout
• 3A, 125VAC; UL
• SPST; latching or momentary
• Solder termination
• Round button actuator
• LED illumination options
• Actuator color options

View Series

PP2 Series

PP2 Series Push-Pull Pushbutton Detector Switch

• 36.5mm x 13.5mm cutout;  Snap-In
• Up to 16A or 1HP; UL
• DPDT;  On-(On) or On-On-(On)
• Pin plunger, or push-pull plunger
• Quick connect termination options
• Black or white body and actuator
• Acts as door interlock or detector

View Series

PP1 Series

PP1 Series Push-Pull Pushbutton Detector Switch

• 28.4mm x 13.5mm cutout;  Snap-In
• Up to 16A or 1HP; UL
• SPDT;  On-(On) or On-On-(On)
• Pin plunger, or push-pull plunger
• Quick connect termination options
• Black or white body and actuator
• Acts as door interlock or detector

View Series

PB66 Series

PB66 Series Illuminated, Power Pushbutton Switch

• 25mm panel cutout;  Snap-In
• 16A, 127VAC; UL; IP66
• DPST; Off-On
• Quick connect termination
• Round button actuator
• LED illuminated power symbol
• Laser etched power symbol option

View Series

PB350 Series

PB350 Series Illuminated, Long Travel Pushbutton Switch

• Through hole
• 30mA, 28VDC
• SPST mom. or SPDT double action
• PC pin termination
• Firm tactile response
• High actuation force
• LED illuminated

View Series

PB300 Series

PB300 Series Long Travel Pushbutton Switch

• Through hole
• 30mA, 28VDC
• SPST mom. or SPDT double action
• PC pin termination
• Firm tactile response
• High actuation force
• Non-illuminated

View Series

PA4 Series

PA4 Series Illuminated, Power Pushbutton Switch

• 19mm x 13mm cutout;  Snap-In
• 16A, 125/250VAC; UL
• SPST or DPST; latching or mom.
• Std. button, or rubber cap (IP65)
• Solder or quick-connect
• LED illumination & marking options
• Actuator and body color options

View Series

LP6 Series

LP6 Series Illuminated Pushbutton Switch

• Through hole
• 12mA, 12VDC
• SPST or DPST; momentary
• PC Pin termination
• Square button actuator
• LED illumination options
• Bi-color & RGB color options

View Series

LP11 Series

LP11 Series Illuminated Pushbutton Switch

• Through hole
• 100mA, 12VDC
• SPST; latching or momentary
• PC Pin termination
• Tactile or non-tactile feel actuator
• Square button; three size options
• LED illumination; bi-color or RGB

View Series

LC Series

LC Series Right Angle Pushbutton Switch

• Through hole right angle
• 300mA, 30VDC
• SPDT or DPDT; latching or mom.
• PC pin termination
• Plunger for cap actuator
• Shorting or non-shorting versions
• Many cap options

View Series

LB22 Series

LB22 Series Illuminated Pushbutton Switch

• 22mm panel cutout
• 3A, 250VAC;  IP65
• SPDT or DPDT; latching or mom.
• Solder termination
• LED illumination options
• Actuator color options
• Silver or gold contact material

View Series

FS5700 Series

FS5700 Series Pushbutton Foot Switch

• 12.2mm panel cutout
• Panel mount, rear
• 1A, 9VDC
• SPDT, DPDT or 3PDT
• Momentary or alternate action
• Solder lug or PC Pin termination
• High actuation force

View Series

800B Series

800B Series Sealed, Subminiature, SMT Right Angle Pushbutton Switch

• IP67 rated
• SMT right angle
• Gold – 0.4VA, 20V max. (AC or DC)
• SPST or SPDT; momentary function
• Gullwing termination
• Gold contact material
• Epoxy sealed terminals

View Series

JS1400 Series

JS1400 Series 5-Position, Joystick Navigation Switch

• SMT
• 50mA, 12VDC
• 4-way directional, center select
• Plunger for cap actuator
• Center: 360gf, Tilt: 160gf
• 7.4mm x 7.7mm body
• Four actuator height options

View Series

JS1300 Series

JS1300 Series 5-Position Navigation Switch

• SMT
• 50mA, 12VDC
• 4-way directional, center select
• Tactile (5 Button) actuator
• Center: 320gf, Tilt: 180gf
• 9.8mm x 9.8mm body
• 1.55mm actuator height

View Series

E200 Series

E200 Series Emergency Stop, Pushbutton Switch

• IP65 rated
• 16mm panel cutout
• Multiple agency approvals
• Contact arrangement options
• Many contact ratings
• Pushlock turn to reset, design
• Multiple illumination options

View Series

E100 Series

E100 Series Emergency Stop, Pushbutton Switch

• IP65 rated
• 16mm panel cutout
• Multiple agency approvals
• Contact arrangement options
• Many contact ratings
• Pushlock turn to reset design
• Multiple illumination options

View Series

KAN Series

KAN Series Low Profile, Half Pitch DIP Switch

• SMT
• 25mA, 24VDC
• Slide actuator; recessed
• 2-10 positions; SPST each position
• 0.050″ (1.27mm) Half pitch
• Gold contact material
• Top tape seal option

View Series

KAE Series

KAE Series Low Profile DIP Switch

• Through hole or SMT
• 25mA, 24VDC
• Slide actuator; raised or recessed
• 1-12 positions; SPST each position
• 0.100″ (2.54mm) Full pitch
• Gold contact material
• Top tape seal option

View Series

DR Series

DR Series Rotary DIP Switch

• Through hole, SMT, or Rt angle
• 25mA, 24VDC
• 2×3, 3×3, or 4×1 pcb terminal layout
• Flush, or shaft actuator
• 10 or 16 positions
• Real code
• 0.100″ (2.54mm), Full pitch

View Series

TD1260 Series

TD1260 Series Ultraminiature SMT Detector Switch

• SMT
• 1mA, 5VDC
• SPST, NO or NC; momentary
• Angled toggle detector
• J lead termination
• Mounting boss
• 35gf max. force;  2.5mm travel

View Series

ST5 Series

ST5 Series High Current, High Temperature, Power Toggle Switch

• 12mm diameter panel cutout;  IP40
• Up to 20A, 125VAC/30VDC, UL
• 1 or 2 pole; latching or momentary
• Solder, QC-tabs, screw, or wires
• Standard metal bat, or plastic bat
• 15/32-32 bushing
• -10°C to 125°C operating temp

View Series

ST4 Series

ST4 Series High Current, Sealed, Power Toggle Switch

• 12mm diameter panel cutout;  IP68
• Up to 20A, 125VAC/30VDC, UL
• 1 or 2 pole; latching or momentary
• Solder, QC-tabs, screw, or wires
• Standard metal bat, or plastic bat
• 15/32-32 bushing
• -10°C to 55°C operating temp

View Series

ST3 Series

ST3 Series High Current, Power Toggle Switch

• 12mm diameter panel cutout
• Up to 24A, 125VAC, UL
• 3 pole; latching
• Solder, QC-tabs, screw, or wires
• Standard bat actuator
• M12 x 1.0 bushing
• 0°C to 85°C operating temp

View Series

ST2 Series

ST2 Series High Current, Power Toggle Switch

• 12mm diameter panel cutout
• Up to 20A, 125VAC, UL
• 2 pole; latching or momentary
• Solder, QC-tabs, screw, or wires
• Standard bat actuator
• M12 x 1.0 or 15/32-32 bushing
• 0°C to 85°C operating temp



View Series

ST1 Series

ST1 Series High Current, Power Toggle Switch

• 12mm diameter panel cutout
• Up to 20A, 125VAC, UL
• 1 pole; latching or momentary
• Solder, QC-tabs, screw, or wires
• Standard or short bat actuator
• M12 x 1.0 or 15/32-32 bushing
• 0°C to 85°C operating temp

View Series

100 Series

100 Series Miniature Toggle Switch

• Panel mount or through hole
• Gold – 0.4VA, 28V max. (AC or DC)
• Silver – 5A, 120VAC or 28VDC; UL
• 1 – 4 pole; latching or momentary
• 17 mounting options
• 11 actuator options
• 15 bushing options

View Series

TL52 Series

TL52 Series Sealed, Through Hole, Radial Lead Tactile Switch

• IP67 rated
• Through hole
• 8.00mm x 8.00mm
• PC Pin termination
• 160gf or 260gf operating force
• 50mA @ 12VDC
• Radial lead packaging

View Series

TL3301 Series

TL3301 Series SMT Tactile Switch

• SMT
• 6.00mm x 6.00mm
• Gull wing or J lead termination
• Many actuator height options
• Cap options for certain models
• 100gf, 160gf, or 260gf
• 50mA @ 12VDC

View Series

TL1105 Series

TL1105 Series Through Hole Tactile Switch

• Through hole, or rt. angle
• 6.00mm x 6.00mm
• PC Pin termination
• Ground terminal option
• Many actuator heights & caps
• 100gf, 160gf, or 250gf
• Silver or gold contact material

View Series

TL1100 Series

TL1100 Series Through Hole Tactile Switch

• Through hole, or rt. angle
• 12.00mm x 12.00mm
• PC Pin termination
• Many actuator heights & caps
• 160gf or 260gf
• Silver or gold contact material
• 50mA @ 12VDC

View Series

TL1030 Series

TL1030 Series Miniature SMT Tactile Switch

• SMT
• 3.50mm x 2.90mm
• J lead termination
• Ground terminal option
• 160gf, 200gf, 350gf, or 500gf
• Silver contact material
• 50mA @ 12VDC

View Series

WS2 Series

WS2 Series Sealed Snap Action Switch

• IP67 rated
• 2A, 30VDC or 250VAC; UL
• Panel mount or through hole
• SPDT On-On
• Solder, quick connect, or PC pin
• Pin plunger actuator
• 183gf max. operating force

View Series

WS1 Series

WS1 Series Sealed Snap Action Switch

• IP67 rated
• 0.1A 48VDC or 125/250VAC; UL
• 3A 12VDC or 125/250VAC;  UL
• SPDT On-On
• Solder or wire leads termination
• Pin plunger actuator
• 130gf max. operating force

View Series

WS Series

WS Series Sealed Snap Action Switch

• IP67 rated
• Chassis mount, or through hole
• 1A 24VDC; 3A 125/250VAC; UL
• SPDT On-(On)
• Solder, PC pin, or wire leads
• Pin plunger, or two lever options
• 50gf or 70gf operating force

View Series

TS2 Series

TS2 Series SMT Snap Action Switch

• SMT
• 100mA, 125VAC or 48VDC
• SPST Off-(On)
• Pin plunger actuator
• 70gf operating force
• 3,000,000 life cycles
• Tape & reel packaged

View Series

TS Series

TS Series Subminiature Snap Action Switch

• Thru hole or thru hole rt. angle
• 300mA, 6VDC
• SPDT On-(On)
• Straight lever actuator
• PC Pin termination
• 20gf operating force
• Silver contact material

View Series

SS Series

SS Series Subminiature Snap Action Switch

• Chassis, thru hole, or rt angle
• Gold – 0.4VA, 20V max. (AC or DC)
• Silver – 3A or 0.1A options; UL
• SPDT On-(Off)
• Solder or PC Pin termination
• Pin plunger, or three lever options
• 15gf – 130gf operating force

View Series

MS Series

MS Series Miniature Snap Action Switch

• Chassis, thru hole, or rt angle
• Gold – 0.4VA, 20V max. (AC or DC)
• Silver – 5A, 125/250VAC; UL, VDE
• SPDT or SPST-NO
• Solder, quick connect, or PC pin
• Pin plunger, or seven lever options
• 10gf – 295gf operating force

View Series

LS Series

LS Series Snap Action Switch

• Chassis or thru hole rt. angle
• Gold – 0.4VA, 20V max. (AC or DC)
• Silver – 15A, 125/250VAC; UL, VDE
• SPDT, SPST-NC or SPST-NO
• Solder, quick connect or PC pin
• Pin plunger or six lever options
• 25gf – 250gf operating force

View Series

EGL2290 Series

EGL2290 Series Illuminated, SMT Slide Switch

• SMT
• 300mA, 6VDC
• DPDT On-On
• LED illumination; color options
• Compact 7.65mm x 5.5mm body
• 200gf operating force
• 2.0mm travel

View Series

EGJ1210 Series

EGJ1210 Series Slide Switch

• SMT, thru hole, or rt. angle
• 300mA, 24VDC
• SPDT On-On
• Gullwing or PC pin termination
• 250gf operating force
• 1.6mm travel
• Gold terminals

View Series

500R Series

500R Series Sealed, Through Hole Slide Switch

• IP67 rated
• Thru hole, or thru hole rt angle
• Gold – 0.4VA, 20V max. (AC or DC)
• SPDT or DPDT; 2 or 3 positions
• 2.8mm actuator length
• PC pin termination
• Epoxy sealed terminals

View Series

500A Series

500A Series Subminiature Slide Switch

• Through hole or SMT
• Gold – 0.4VA, 20V max. (AC or DC)
• Silver – 3A, 120VAC; 1A, 250VAC; UL
• SPDT; 2 or 3 positions; latching
• Vertical or right angle actuation
• PC pin or gullwing termination
• Epoxy sealed terminals

View Series

KC1901 Series

KC1901 Series Rotary Switch

• Through hole
• 100mA, 16VDC
• SP9T – Single pole, 9 positions
• Non-shorting (BBM)
• Shaft actuator, 9.8mm height
• 11.40mm x 12.40mm body
• Silver contact material

View Series

KC Series

KC Series Rotary Switch

• 9.8mm diameter panel cutout
• 350mA, 125VAC
• 1-4 poles, 1-12 positions
• Non-shorting or shorting timing
• Solder lug or PC pin termination
• Many actuator lengths and styles
• Silver or gold contact material

View Series

WB2 Series

WB2 Series Sealed, Power Rocker Switch

• 30mm x 22mm panel cutout
• Up to 20A, 125/250VAC; UL; IP55
• DPST or DPDT; latching or mom.
• Quick connect, or wire leads
• Housing and actuator color options
• Actuator marking options
• Non-illuminated

View Series

RVW Series

RVW Series Sealed, Power Rocker Switch

• 36.8mm x 21mm panel cutout
• Up to 20A, 125VAC; UL; IP54
• 1 or 2 pole; latching or mom.
• QC-tabs, solder, screw, or wires
• Housing and actuator color options
• Actuator marking options
• Matte or Glossy finish

View Series

RSC Series

RSC Series Illuminated, Power Rocker Switch with Bi-Color Actuator

• Four panel cutout options
• Up to 20A, 125VAC; UL; IP54
• SPST or SPDT; latching or mom.
• Quick connect, solder, or wires
• Housing and actuator color options
• LED illumination options
• Actuator marking options

View Series

RRG3 Series

RRG3 Series Round, Power Rocker Switch

• 20mm diameter panel cutout
• Up to 16A, 125VAC; UL
• SPST or SPDT; latching or mom.
• Quick connect, solder, or wires
• Housing and actuator color options
• Non-illuminated, glossy finish
• Actuator marking options

View Series

RRA Series

RRA Series Round, Illuminated, Power Rocker Switch with PVC Cap

• 22mm diameter panel cutout
• Up to 15A, 125VAC; UL
• 1 or 2 pole; latching
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options
• IP54 with PVC cap: ACC-P04

View Series

RR8 Series

RR8 Series Round, Illuminated, Power Rocker Switch with PVC Cap

• 20mm diameter panel cutout
• Up to 16A, 125VAC; UL
• DPST; Off-On
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options
• IP54 with PVC cap: ACC-P03

View Series

RR5 Series

RR5 Series Round, Power Rocker Switch

• 20mm diameter panel cutout
• Up to 20A, 125VAC; UL
• SPST; latching or momentary
• Quick connect, solder, or wires
• Housing and actuator color options
• Actuator marking options
• Short body design

View Series

RR3402 Series

RR3402 Series Round, Paddle Style, Power Rocker Switch

• 15mm diameter panel cutout
• Up to 6A, 125VAC; UL
• SPST or SPDT; latching
• Solder, or wire leads termination
• Black housing and actuator
• Paddle style actuator
• Threaded body with nut design

View Series

RR3112 Series

RR3112 Series Round, Illuminated, Power Rocker Switch

• 20.2mm diameter panel cutout
• Up to 16A, 125VAC; UL
• SPST or SPDT; latching or mom.
• Quick connect, or wire leads
• Housing and actuator color options
• LED or NEON illumination options
• Actuator marking options

View Series

RR1 Series

RR1 Series Round, Illuminated, Power Rocker Switch with PVC Cap

• 20mm diameter panel cutout
• Up to 16A, 125VAC; UL
• SPST or SPDT; latching
• Quick connect, solder, or wires
• LED illumination options
• Actuator marking options
• IP54 with PVC cap: ACC-P03

View Series

RE1 Series

RE1 Series Oval, Illuminated, Power Rocker Switch

• 23.3mm x 13.5mm Oval cutout
• Up to 16A, 125VAC; UL
• SPST or SPDT; latching
• Quick connect, or wire leads
• Housing and actuator color options
• LED illumination options
• Actuator marking options

View Series

RD1 Series

RD1 Series Compact, Power Rocker Switch

• 19.2mm x 6.8mm panel cutout
• Up to 16A, 125VAC; UL
• SPST Off-On
• Quick connect, or wire leads
• Housing and actuator color options
• Non-illuminated
• Actuator marking options

View Series

RBW2 Series

RBW2 Series Sealed, Illuminated, Power Rocker Switch

• 30mm x 22mm panel cutout
• Up to 16A, 125VAC; UL; IP66
• DPST or DPDT; latching
• Quick connect, or wire leads
• Housing and actuator color options
• LED illumination options
• Actuator marking options

View Series

RB5 Series

RB5 Series Sealed, Illuminated, Power Rocker Switch

• 30.2mm x 22mm panel cutout
• IP67 rated
• Up to 25A, 125VAC; UL
• DPST or DPDT; latching or mom.
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options

View Series

RB3 Series

RB3 Series Sealed, Illuminated, Power Rocker Switch

• 30.2mm x 13.8mm panel cutout
• IP67 rated
• Up to 25A, 125VAC; UL
• SPST or SPDT; latching or mom.
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options

View Series

RB2 Series

RB2 Series Illuminated, Power Rocker Switch with PVC Cap

• 30mm x 22mm panel cutout
• Up to 20A, 125VAC; UL
• DPST or DPDT; latching or mom.
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-F02

View Series

RB1 Series

RB1 Series Illuminated, Power Rocker Switch with PVC Cap

• 30mm x 11mm panel cutout
• Up to 20A, 125VAC; UL
• SPST or SPDT; latching or mom.
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-F01

View Series

RA8 Series

RA8 Series Illuminated, Power Rocker Switch with PVC Cap

• 19.2mm x 13mm panel cutout
• Up to 16A, 125VAC; UL
• SPST or DPST; Off-On
• Quick connect, PC pin, or wires
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-P01

View Series

RA4 Series

RA4 Series Illuminated, Power Rocker Switch with PVC Cap

• 22mm x 19.2mm panel cutout
• Up to 16A, 125VAC; UL
• 1 or 2 pole; latching or mom.
• Quick connect, PC pin, or wires
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-P02

View Series

RA1 Series

RA1 Series Illuminated, Power Rocker Switch with PVC Cap

• 19.2mm x 13mm panel cutout
• Up to 16A, 125VAC; UL
• SPST or SPDT; latching or mom.
• QC-tabs, solder, PC pin, or wires
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-P01

View Series

R7 Series

R7 Series Sealed, Illuminated, Power Rocker Switch

• 37mm x 21.2mm panel cutout
• Up to 20A, 125VAC; UL; IP67
• 1 or 2 pole; latching or mom.
• QC-tabs, solder, screw, or wires
• Many actuator style options
• LED illumination options
• Custom actuator marking avail.

View Series

R6 Series

R6 Series Slim, Power Rocker Switch

• 19.2mm x 6.65mm panel cutout
• 10A, 125VAC; UL
• SPST; latching or mom.
• Quick connect, or wire leads
• Housing and actuator color options
• Non-illuminated
• Actuator marking options

View Series

R5 Series

R5 Series Illuminated, Power Rocker Switch

• 30mm x 22mm panel cutout
• Up to 20A, 125VAC; UL
• DPST or DPDT; latching or mom.
• Quick connect, or wire leads
• Actuator color options
• LED or Neon illumination options
• Actuator marking options

View Series

TD1250 Series

TD1250 Series Sealed, Long Life Detector Switch

• Through hole or Panel Mount
• Up to 50mA, 16VDC;  IP67 rated
• SPST Off-(On)
• Pin plunger, or lever options
• PC Pin or solder termination
• 160gf max. operating force
• Silver contact material

View Series

TD1150 Series

TD1150 Series Sealed Detector Switch

• Through hole
• 100mA, 12VDC;  IP67 rated
• SPST Off-(On)
• Pin plunger actuator
• PC Pin termination
• 35gf electrical make (.5mm travel)
• 100gf full stroke (2.5mm travel)

View Series

TD1146 Series

TD1146 Series Ultraminiature SMT Detector Switch

• SMT
• 1mA, 5VDC
• SPST Off-(On)
• Angled toggle detector
• Gullwing termination
• 50gf max. force;  3.0mm travel
• Silver contact material

View Series

900 Series

900 Series Subminiature SMT Right Angle Detector Switch

• SMT right angle
• 100mA, 50VDC
• SPST; NO or NC; momentary
• Overtravel plunger actuator
• Gullwing termination
• Mounting boss option
• 50gf max. force;  2.0mm travel

View Series

ECM3026 Series

ECM3026 Series PCB Header

• Free hanging 3mm spacing
• Wire-wire-receptacle-plug system
• Compatible with ECM3025
• Low profile design
• Two, four, six or 10 poles

View Series

ECM3025 Series

ECM3025 Series Free Hanging Receptacle Housing

• Free hanging 3mm spacing
• Wire-wire-receptacle-plug system
• Compatible w/ECM3022 ECM3026
• Low profile design
• Two, four, six or 10 poles
• Wire leads 500mm option
• ECM5556F2822C – socket term.

View Series

ECM3022 Series

ECM3022 Series Free Hanging Plug Housing

• Free hanging 3mm spacing
• Wire-wire-receptacle-plug system
• Compatible with ECM3025
• Low profile design
• Two, four six or 10 poles
• Wire leads 500mm option
• ECM5558M2822C – pin term.

View Series

ULV8 Series

ULV8 Series UL Certified, Illuminated Anti-Vandal Switch

• 25mm panel cutout
• 3A, 125/250VAC, UL;  IP67 rated
• SPDT or DPDT; latching or mom.
• Flat actuator
• Solder, wire leads, or socket
• LED ring, ring/power, or graphic
• Stainless steel or black anodized

View Series

ULV7 Series

ULV7 Series UL Certified, Illuminated Anti-Vandal Switch

• 22mm panel cutout
• 3A, 125/250VAC, UL;  IP67 rated
• SPDT or DPDT; latching or mom.
• Flat actuator
• Solder, wire leads, or socket
• LED ring, ring/power, or graphic
• Stainless steel or black anodized

View Series

ULV4 Series

ULV4 Series UL Certified, Illuminated Anti-Vandal Switch

• 19mm panel cutout
• 3A, 125/250VAC, UL;  IP67 rated
• SPDT or DPDT; latching or mom.
• Flat, high, or domed actuator
• Solder, wire leads, or socket
• LED dot, ring, power, or graphic
• Nickel, stainless steel, or black

View Series

SV8 Series

SV8 Series Illuminated, Short Body Anti-Vandal Switch

• 25mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST Off-(On)
• Short body design; flat actuator
• Solder or wire leads 500mm
• with ECM Connector option
• LED ring or ring/power symbol

View Series

SV7 Series

SV7 Series Illuminated, Short Body Anti-Vandal Switch

• 22mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST Off-(On)
• Short body design; flat actuator
• Solder or wire leads 500mm
• with ECM Connector option
• LED ring or ring/power symbol

View Series

SV4 Series

SV4 Series Illuminated, Short Body Anti-Vandal Switch

• 19mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST Off-(On)
• Short body design; flat actuator
• Solder or wire leads 500mm
• with ECM Connector option
• LED ring or ring/power symbol

View Series

SAV8 Series

SAV8 Series Illuminated, High Current Anti-Vandal Switch

• 25mm panel cutout
• 15A, 125/250VAC;  IP67 rated
• SPDT; latching or momentary
• Pre-mounted on LS Series switch
• Quick connect 0.187″ or wire leads
• LED ring, or ring/power symbol
• Stainless steel or black anodized

View Series

PZ Series

PZ Series Illuminated Anti-Vandal, Piezo Switch

• 16mm, 19mm, or 22mm cutout
• 1A, 24VDC;  IP68 rated
• SPST Off-(On);  Piezo switch
• Concave or flat bezel
• Wire leads with connector
• LED ring, or non-illuminated
• Clear anodized or black anodized

View Series

PVT4 Series

PVT4 Series Illuminated, Tactile Response Anti-Vandal Switch

• 19mm panel cutout
• 50mA, 24VDC;  IP65 rated
• SPST Off-(On)
• Tactile response; 0.5mm travel
• Solder or wire leads 300mm
• LED ring illumination
• Stainless steel or black anodized

View Series

PVS7 Series

PVS7 Series Illuminated Anti-Vandal Switch

• 22mm panel cutout
• 2A, 24VDC;  IP65 rated
• SPDT or DPDT; latching or mom.
• Square bezel; flat actuator
• Solder or wire leads 300mm
• LED ring, or etched power symbol
• Stainless steel finish

View Series

PVP Series

PVP Series Anti-Vandal Switch Socket

• Socket extension for PV Series
• Solder or wire leads 140mm
• SPDT or DPDT circuit
• LED illuminated or non-illuminated
• Use with PV3, 4, 7, 8, 9, 10, or PVB3
• Order socket separate from switch

View Series

PVL Series

PVL Series Illuminated Pilot Indicator

• 6mm-25mm panel cutout
• Pilot lamp indicator;  IP67 rated
• Flat or domed lens style
• Solder, screw, or wire leads 150mm
• LED illuminated, many colors
• Stainless steel, black, or nickel
• 40,000 hours nominal lamp life

View Series

PVK4 Series

PVK4 Series Illuminated Anti-Vandal Switch

• 19mm panel cutout
• 2A, 24VDC;  IP65 or IP40 rated
• 1 or 2 poles; 2 or 3 positions
• Keylock or selector actuator
• Solder or wire leads
• Stainless steel finish
• LED illumination options

View Series

PVHC7 Series

PVHC7 Series Illuminated, High Current Anti-Vandal Switch

• 22mm panel cutout
• 20A, 250VAC, UL;  IP67 rated
• SPST; latching or momentary
• Flat actuator
• Solder or wire leads
• LED ring or ring/power symbol
• Stainless steel or black anodized

View Series

PVHC4 Series

PVHC4 Series Illuminated, High Current Anti-Vandal Switch

• 19mm panel cutout
• 20A, 250VAC, UL;  IP67 rated
• SPST; latching or momentary
• Flat actuator
• Solder or wire leads
• LED ring or ring/power symbol
• Stainless steel or black anodized

View Series

PVB3 Series

PVB3 Series Illuminated Anti-Vandal Switch

• 16mm panel cutout
• 2A, 24VDC, UL;  IP67 rated
• SPDT; latching or momentary
• High or flat actuator
• Solder or wire leads
• LED ring or ring/power symbol
• Stainless steel or black anodized

View Series

PVA6 Series

PVA6 Series Illuminated, Long Life Anti-Vandal Switch

• 16mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST; latching or momentary
• Domed, high or flat bezel/actuator
• Solder, wire leads, or molded back
• LED ring or ring/power symbol
• Stainless steel, clear, or black

View Series

PV9 Series

PV9 Series Illuminated Anti-Vandal Switch

• 28m panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC or 4PST-2NO/2NC
• Flat actuator
• Solder or wire leads 300mm
• LED ring or dot
• Stainless steel or black anodized

View Series

PV8 Series

PV8 Series Illuminated Anti-Vandal Switch

• 25m panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC or 4PST-2NO/2NC
• Flat actuator
• Solder or wire leads 300mm
• LED ring, dot or power symbol
• Stainless steel or black anodized

View Series

PV7 Series

PV7 Series Illuminated Anti-Vandal Switch

• 22m panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC latching or mom.
• Flat actuator
• Solder or wire leads 300mm
• LED ring, dot or power symbol
• Stainless steel or black anodized

View Series

PV6 Series

PV6 Series Illuminated Anti-Vandal Switch

• 16mm panel cutout
• 2A, 48VDC;  IP65 rated
• SPST Off-(On) or Pilot Indicator
• High or flat actuator
• Solder or wire leads 300mm
• LED ring, dot, or power symbol
• Stainless steel, nickel or black

View Series

PV4 Series

PV4 Series Illuminated Anti-Vandal Switch

• 19mm panel cutout
• 2A, 24VDC;  IP67 rated*
• SPDT, DPDT, or DPDT-NO/NC
• High, or flat actuator
• Solder, screw, or wire leads
• LED ring, dot, or power symbol
• Stainless steel or black anodized

View Series

PV3 Series

PV3 Series Illuminated Anti-Vandal Switch

• 16mm panel cutout
• 2A, 48VDC;  IP67 or IP40 rated
• SPDT or DPDT; momentary
• Long or short body
• Flat, high, or guarded actuator
• Solder or wire leads 300mm
• LED ring or dot

View Series

PV2 Series

PV2 Series Long Life Anti-Vandal Switch

• 16mm panel cutout
• 2A, 48VDC;  IP65 rated
• SPST Off-(On)
• Domed, high, or flat actuator
• Solder, screw, or wire leads
• Non-illuminated
• Gold, nickel, stainless, or black

View Series

PV10 Series

PV10 Series Illuminated Anti-Vandal Switch

• 40mm panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC or 4PST-2NO/2NC
• Flat actuator
• Solder or wire leads 300mm
• LED ring or dot
• Stainless steel or black anodized

View Series

PV1 Series

PV1 Series Long Life Anti-Vandal Switch

• 19mm panel cutout
• 2A, 36VDC;  IP65 rated
• SPST Off-(On)
• Domed, high, or flat actuator
• Solder, screw, or wire leads
• Non-illuminated
• Gold, nickel, stainless, or black

View Series

PV0 Series

PV0 Series Illuminated Anti-Vandal Switch

• 12mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST Off-(On)
• High or flat actuator
• Solder or wire leads 300mm
• LED ring, dot, or power symbol
• Stainless steel or black anodized

View Series

PMV6 Series

PMV6 Series Anti-Vandal Switch

• 16mm panel cutout
• 2A, 24VDC;  IP67 rated
• SPST or SPDT; momentary
• Wire leads termination
• Actuator color options
• Black nylon 6/6 housing
• Crisp tactile response

View Series

CS Series

CS Series Illuminated, Touch Sensor Anti-Vandal Switch

• 19mm or 22mm panel cutout
• 1A, 5-24VDC;  IP68 rated
• SPST; latching or momentary
• Touch sensor, capacitive switch
• Wire leads with connector
• LED ring, or ring/power symbol
• Aluminum, clear anodized finish

View Series
