Tact

Tact switches are commonly used in many consumer electronic devices. They have a small footprint and come in many sizes and gram forces.

320 Series Tactile | Pushbutton Switches

• 135 ± 50 gram force
• PC board mounting design
• Variety of caps available
• Silver plated contacts

RT1105 Series Top Actuated, Reverse Through-hole Tact Switch

  • 100,000 cycle life expectancy
  • Tray packaging
  • Top actuated, reverse through-hole
  • Multiple Gram Force Options – 160gf (red), 260gf (dark gray), 350gf (blue)

TL1014 Series Subminiature, Right Angle Tactile Switch

• Long life expectancy of up to 200,000 cycles
• 160 or 220 gram force options
• Right angle, surface mount design
• Silver plated contacts

TL1015 Series Ultraminiature Tactile Switch

• 3mm x 4mm tactile switch
• 160 ± 50 gram force
• Surface mount design
• Silver plated contacts

TL1016 Series Micro-Miniature Right Angle SMT Tact Switch

  • 3.55 x 3.5mm tactile switch
  • 160 or 220 gram force options
  • Right angle surface mount design
  • Up to 100,000 cycle life expectancy
  • Ground terminal option

TL1100 Series Tactile Switch

• 12mm x 12mm tactile switch
• 160 ± 50; 260 ± 50 gram force options
• Vertical and right angle designs
• Silver or gold plated contacts

TL1105 and TLE1105 Series Tactile Switches

• 6mm x 6mm tactile switch
• 100 ± 50; 160 ± 50; 250 ± 50 gram force options
• Vertical and right angle designs
• Silver or gold plated contacts

TL1107 Series Tactile Switch

• 3.5mm x 6mm tactile switch
• 130 ± 50; 180 ± 50; 260 ± 50 gram force options
• Straight, reverse, and side retention termination options
• Silver plated contacts

TL1220 Series Illuminated, Multi-option Tactile Switch

• Multiple illuminated cap options
• Single color LED options
• 180 ± 50 gram force
• PC board mount design

TL1240 Series Illuminated Tactile Switch

• 6mm x 6mm tactile switch
• 160 ± 50 gram force
• Multiple LED color options
• Silver plated contacts

TL1250 Series Illuminated, Right Angle Tactile Switch

• 6.8mm x 8.3mm tactile switch
• Single color LED options in blue, red, green, and yellow
• Right angle, through-hole mounting design
• Silver or gold plated contacts

TL1260 Series Illuminated, Right Angle Tactile Switch

• 6.8mm x 7mm tactile switch
• 160 ± 50 gram force option
• LED illumination options
• Right angle, through hole mount design

TL1265 Series Illuminated Vertical Tactile Switch

• 6.8mm x 7mm tactile switch
• Long life expectancy of 500,000 cycles
• LED illumination options
• Vertical, through-hole mounting design

TL1275 Series Tactile Switch with Wire Leads and Connectors

• 500mm long wire leads with connectors
• Single color and bi-color LED options
• Sharp tactile response
• Panel Mount

TL2243 Series Double Stacked, Low Profile Tactile Switch

• 7.3mm x 9.1mm tactile switch
• 180 ± 50 gram force option
• Dual actuation
• Right angle through hole mount design

TL3145 Series Long Life, SMT Tactile Switch

  • Long life expectancy up to 3,000,000 cycles
  • Tactile tape and reel packaging
  • IP67 ratings
  • Multiple operating force options

TL3200 Series SMT, Dual LED Illuminated Tactile Switch

• 6.8mm x 4.5mm tactile switch
• 160 +75/-30 gram force
• Single or dual illumination options
• Surface mount design

TL3210 Series Miniature, LED Illuminated Tact Switch

• 5.6mm x 3.4mm tactile switch
• 160 ± 50 gram force options
•  Illuminated SMT
• Tape & reel packaging

TL3215 Series Ultraminiature SMT, LED Illuminated Tactile Switch

• 50mA 12VDC rating
• Multiple LED colors
• Long life of 1 million cycles
• SMT, low profile, ultra miniature

TL3240 Series LED Illuminated, SMT Tactile Switch

• 6mm x 7.8mm tactile switch
• 100gf, 160gf, and 260gf options
• Surface mount design
• Tactile tape and reel packaging

TL3253 Series Dual LED Illuminated Tactile Switch

• 7.5mm x 22.6mm tactile switch
• 160 gram force
• Dual LEDs
• Right angle mount

TL3265 Series LED Illuminated, SMT Tactile Switch

• 500,000 cycle life expectancy
• Multiple cap options
• Surface mount design
• Illumination options

TL3300 Series SMT Tactile Switch

• 12mm x 12mm tactile switch
• 160, 260, 320, 520 gram force options
• Surface mount design
• Multiple actuator options

TL3301 Series SMT Tactile Switch

• 6mm x 6mm tactile switch
• 100, 160, and 260 gram force options
• Surface mount design
• Silver or gold plated contacts

TL3302 Series 3.5mm x 6mm SMT Tactile Switch

• 3.5mm x 6mm tactile switch
• 130 ± 50; 180 ± 50; 260 ± 50 gram force options
• Surface mount design
• Silver plated contacts

TL3303 Series SMT Tactile Switch

• 6mm x 6mm tactile switch
• 100 ± 50; 160 ± 50; 260 ± 50 gram force options
• Surface mount design
• Silver plated contacts

TL3305 Series Ultraminiature, SMT Tactile Switch

  • Ultraminiature, 4.5 x 4.5mm
  • Multiple actuator options
  • Surface mount
  • Multiple operating force options

TL3312 Series Miniature, Low Profile, SMT Tactile Switch

  • Ultraminiature, 3.7mm x 3.7mm in size
  • Surface mount termination
  • Very low profile of 0.35mm

TL3313 Series Subminiature, SMT Tactile Switch

• 4.8mm x 4.8mm tactile switch
• 100 ± 50; 160 ± 50; 250 ± 50 gram force options
• Surface mount design
• Silver plated contacts

TL3315 Series Ultra Low Profile, SMT Tactile Switch

• 4.5mm x 4.5mm tactile switch
• Ultra low profile with 0.55mm height
• 100 ± 30; 160 ± 50; 250 ± 50 gram force options
• Surface mount design

TL3330 Series SMT, Right Angle Tactile Switch

• 6.9mm x 3.3mm tactile switch
• 100 ± 40; 200 ± 50 gram force options
• Right angle surface mount design
• Silver plated contacts

TL3336 Series Sealed, Right Angle SMT Tactile Switch

  • 100,000 cycle life expectancy
  • Tactile tape and reel packaging
  • IP67 rating for dust and moisture protection
  • Right angle, surface mount design

TL3340 Series Right Angle SMT, Subminiature Tactile Switch

• 4.25mm x 3.3mm tactile switch
• 160 ± 50gf and 130gf ± 30gf options
• Right angle surface mount design
• Silver plated contacts

TL3342 Series Low Profile, SMT Tactile Switch

• 5.2mm x 5.2mm tactile switch
• Ultra low profile with 1.50mm height
• 160 ± 50; 250 ± 50 gram force options
• Surface mount design

TL3360 Series Right Angle, SMT Tactile Switch

• Right angle surface mount
• 185 or 260 gram operating force
• Multiple actuation options
• SPST

TL3365 Series Ultraminiature, SMT Tactile Switch

  • Ultraminiature size: 3.2mm x 4.2mm
  • Surface mount
  • 100,000 electrical / mechanical life
  • SPST, 180gf, 250gf, or 400gf

TL3701 Series Ultraminiature Micro Tactile SMT Switch

• 3.0mm x 2.6mm x 0.65mm tactile switch
• Up to 100,000 cycles life expectancy
• 100gf and 160gf options
• Surface mount design

TL3780 Series Ultraminiature, Low Profile SMT Tactile Switch

• Ultraminiature 2.0mm x 3.0mm size
• Surface mount termination
• Very low profile of 0.60mm
• Multiple operating forces

TL3901 Series Subminiature Right Angle, Edge Mounted SMT Tactile Switch

• 4.3mm x 6.10mm tactile switch
• 180 ± 50 gram force
• Right angle surface mount design
• Silver plated contacts

TL4100 Series Miniature, Right Angle Edge Tactile Switch

• 1,000,000 cycle life expectancy
• 120 and 240 gram force options
• Unique pcb edge-mounting design

TL4105 Series Right Angle Edge, Ultraminiature Tactile Switch

• 200,000 cycle life expectancy
• 160 gram force option
• Unique PCB, edge-mounting design

TL4110 Series Low Profile, SMT Tactile Switch

• Surface Mount Switch
• Long Cycle Life of 300,000 Cycles
• Extremely Small Surface profile of 2.0mm x 2.8mm
• Switch Mounts along the edge of the PCB for Right Angle Actuation

TL4115 Series Right Angle Edge, SMT Tactile Switch

  • 600,000 cycle life expectancy
  • Tactile tape and reel packaging
  • Low travel
  • Right angle edge, surface mount design

TL52 Series Sealed, Radial Lead Tactile Switch

• 8mm x 8mm tactile switch
• 160 ± 50; 260 ± 50 gram force options
• Through-hole mount design
• IP67 sealed for dust and moisture protection

TL58 Series Right Angle, PCB Pin Tactile Switches with Radial Lead Packaging

• 6.2mm x 6.2mm tactile switch
• 100 ± 50; 160 ± 50; 260 ± 50 gram force options
• Designed for automatic feed with radial lead packaging
• Right angle mount design

TL59 Series Radial Lead Tact Switch

• 6.2mm x 6.2mm tactile switch
• 100 ± 50; 160 ± 50; 260 ± 50 gram force options
• Designed for automatic feed with radial lead packaging
• Vertical mount design

TL6100 Series Process Sealed, PCB Pin Tactile Switch

• Process sealed tactile switch
• 130,160, 300, and 500 gram force options
• Through-hole design
• Silver or gold plated contacts

TL6105 Series Process Sealed Tactile Switch with Earth Ground Terminal

• Process sealed tact switch with earth ground terminal
• 130, 160, 300, and 500 gram force options
• Long life of up to 1 million cycles

TL6110 Series Process Sealed, Right Angle Tactile Switch

• Process sealed tactile switch
• 130, 160, 300, and 500 gram force options
• Right angle design
• Long life of up to a million cycles

TL6120 Series Process Sealed, SMT Tactile Switch

• Process sealed tactile switch
• 130, 160, 300, and 500 gram force options
• Surface mount design
• Long life of up to a million cycles

TL6150 Series Sealed, Long Life Tactile Switch

  • Up to 5,000,000 cycle life expectancy
  • Tactile tape and reel packaging
  • IP67 rating for dust and moisture protection
  • Multiple force options

TL6155 Series Right Angle, Sealed SMT Tactile Switch

  • Life expectancy of up to 300,000 cycles
  • Tactile tape and reel packaging
  • IP67 rating for dust and moisture protection
  • Right angle, surface mount design

TL6170 Series Mid-sized, Sealed Tactile Switch with Tall Actuator

• Up to 300,000 cycle life expectancy
• Tactile tape and Reel packaging
• IP67 rating
• Surface mount design
• Actuation force options and two tall actuator options

TL6190 Series Sealed, Right Angle Tactile Switch

• 12.04mm x 11.50mm tactile switch
• 160 ± 60; 220 ± 60; 320 ± 60 gram force options
• Right angle, through-hole mount design
• Process sealed

TL6200 Series Sealed, Long Life Tactile Switch

• Long life of up to 10,000,000 cycles
• Multiple actuator heights
• SMT or Thru Hole termination
• IP67 rating for dust and moisture protection

TL6210 Series Miniature, Sealed, Illuminated Tactile Switch

  • Surface mount termination
  • IP67 rating for dust and moisture protection
  • Multiple LED color options
  • Small package size

TL6215 Series Right Angle, Illuminated, Sealed Tactile Switch

• 50mA @12VDC contact rating
• Illuminated with cap options
• SPST momentary (500,000 life cycles)
• IP67 sealed; right angle or vertical

TL6275 Series Subminiature, LED Illuminated Tactile Switch

  • PCB Mount
  • Illumination options
  • Multiple cap/lens options
  • 100,000 cycle life expectancy
  • Capable to withstand a typical water wash

TL6300 Series PCB Mount, High-Temperature Tactile Switch

• 10,000,000 cycle life expectancy
• IP67 rated dust and moisture protection
• PCB Mount
• Sharp tactile response

TL6330 Series High-Temperature, SMT Tactile Switch

• IP67 rating for dust and moisture protection
• Surface mount, PC board design
• Long life up to 200,000 cycles
• Small package size of 2.80mm x 4.60mm, with two actuator height options
• 200gf, 300gf, 400gf options

TL6340 Series Right Angle, SMT Tactile Switch

  • IP67 rated moisture and dust protection
  • SPST contact arrangement
  • 2.90mm (W) x 3.85mm (L) x 2.00mm (H) dimensions
  • Up to 200,000 cycle life expectancy
  • Right angle surface mount design

TL6400 Series Sealed Tactile Switch

  • IP67 rating for dust and moisture protection
  • 3.5mm x 6mm tactile switch
  • 160 ± 50; 260 ± 70 gram force options
  • 4.3mm; 5.0mm actuator height options
  • Surface mount design

TL6700 Series Sealed SMT Tactile Switch

• 6.9mm x 6.2mm tactile switch
• 160 ± 50; 260 ± 50 gram force options
• Surface mount design
• Process sealed

TL6800 Series Sealed, SMT Tactile Switch

  • IP67 rated
  • 6.3mm x 6.2mm tactile switch
  • Long life expectancy of up to 1,000,000 cycles
  • 160 ± 50; 260 ± 50 gram force options
  • surface mount design

TL9100 Series Soft Touch, SMT J-Bend Tactile Switch

• Single pole, single throw (SPST)
• Multiple actuation forces
• “Soft Touch” tactile switch
• Surface mount device

TL9210 Series Long Travel, SMT J-bend Tactile Switch

  • Surface mount termination
  • Multiple operating force options
  • Long travel and quiet tactile feel
  • Low contact resistance

TL9320 Series Sealed Tactile Switch

  • IP67 rated for dust and moisture protection
  • SPST contact arrangement
  • 8.4mm (W) x 8.4mm (L) x 3.95mm (H) dimensions
  • Long life expectancy up to 500,000 cycles

YTD-Legacy Products

  • Product Change Notifications
  • E-Switch Replacement Series
  • Active Drawing Reference
