ULP Series Illuminated Pushbutton Switch

ULP Series Illuminated Pushbutton Switch Wire Leads & Connectors Available

ULP Series: ULP12OAP1RSFCL1RGB

Categories: PUSHBUTTON

  • document Series Data Sheet
  • document Spec Sheet (2D)

RoHS Compliant REACH Compliant UL Certified

ULP Series Illuminated Pushbutton Switch

Series Configurator

Use the configurator below to find your specific product or view the most common configurations for this product*.

* If you need further customization, we can help!

Current Configuration:

ULP12OAP1RSFCL1RGB

... in stock, available to buy now.

Additional Purchase Options:
Check Distributor Stock Request Sample

Stock Check for ULP12OAP1RSFCL1RGB

Not the product you are looking for? Configure your product

In the table below, find in-stock purchase options for the ULP12OAP1RSFCL1RGB from our authorized distributors.

In-Stock Distributors

PUSHBUTTON, 100mA, 28VDC, SPDT, On-(On), Through Hole, Illuminated

Powered by oemsecrets

About ULP Series

  • Single pole or double pole functions
  • Multiple color options including RGB
  • Multiple cap color and style options
  • PC pin or solder lug termination
  • Latching or momentary options
  • Gold or silver contact material
  • Electrical Life: 200,000 cycles
  • Mechanical Life: 1,000,000 cycles
  • Travel: 2.20mm
  • Operating/Storage Temperature: -40°C to 85°C

ULP Series Markets

Telecommunications

Product Specifications

ULP12OAP1RSFCL1RGB

PUSHBUTTON, 100mA, 28VDC, SPDT, On-(On), Through Hole, Illuminated

  • Series Name ULP
  • PackagingBulk
  • Current Rating100mA
  • Voltage Rating28VDC
  • CircuitSPDT
  • FunctionOn-(On)
  • Mounting TypeThrough Hole
  • Termination TypePC Pin
  • Contact MaterialGold
  • Actuator TypeSquare, Button
  • Illumination StyleFull
  • Illumination ColorLED, RGB
  • Operating Temperature-40°C to 85°C

Support for ULP12OAP1RSFCL1RGB

Not the product you are looking for? Configure your product

Product Inquiry Request Sample
