RCA1913 Series Sealed, Power Rocker Switch

RCA1913 Series Sealed, Power Rocker Switch Wire Leads & Connectors Available

RCA1913 Series: RCA1913S2ABLKBLKNN

Categories: ROCKER

RoHS Compliant REACH Compliant UL Certified ENEC Certified

RCA1913 Series Sealed, Power Rocker Switch

Series Configurator

Use the configurator below to find your specific product or view the most common configurations for this product*.

* If you need further customization, we can help!

Current Configuration:

RCA1913S2ABLKBLKNN

... in stock, available to buy now.

Additional Purchase Options:
Check Distributor Stock Request Sample

Stock Check for RCA1913S2ABLKBLKNN

Not the product you are looking for? Configure your product

In the table below, find in-stock purchase options for the RCA1913S2ABLKBLKNN from our authorized distributors.

In-Stock Distributors

ROCKER, 16A, 125VAC, SPDT, On-On, Panel Mount, Snap-In

Powered by oemsecrets

About RCA1913 Series

  • 19.2mm x 13mm panel cutout; IP68
  • Electrical Ratings:
    • 16(8)A, 125/250VAC; UL
    • 10(4)A, 125/250VAC; UL
    • 16A, 30VDC; UL
  • SPST or SPDT circuit; 2 or 3 position latching function
  • Quick connect, solder, PC pin, PC pin right angle, or wire leads
  • Housing and actuator color options
  • Actuator marking options
  • UL File #E194579 and ENEC File #ENEC-05335-A1

RCA1913 Series Rocker Switch | E-Switch E-Bits

RCA1913 Series Markets

Agricultural

Product Specifications

RCA1913S2ABLKBLKNN

ROCKER, 16A, 125VAC, SPDT, On-On, Panel Mount, Snap-In

  • Series Name RCA1913
  • PackagingBulk
  • Current Rating16A
  • Voltage Rating125VAC
  • CircuitSPDT
  • FunctionOn-On
  • Mounting TypePanel Mount, Snap-In
  • Termination TypeSolder
  • Actuator TypeConcave (Curved)
  • Actuator ColorBlack
  • Illumination StyleNon-illuminated
  • Illumination ColorNon-illuminated
  • Ingress ProtectionIP68
  • Panel Cutout DimensionsRectangular - 19.2mm x 13mm
  • Operating Temperature0°C to 55°C


Support for RCA1913S2ABLKBLKNN

Not the product you are looking for? Configure your product

Product Inquiry Request Sample
