• Through Hole
• 100mA, 125VAC or 48VDC
• PC Pin termination
• SPST Off-(On)
• Pin plunger actuator
• 70gf operating force
• Silver contact material

• SMT
• 2.0mm x 2.8mm
• 0.65mm actuator height
• 160gf operating force
• Gull wing termination
• 300,000 cycle life
• 0.13mm travel

• 19.2mm x 13mm panel cutout
• 9A, 125VAC; UL
• SPST or DPST; latching or mom.
• QC-tabs, PC pin, or wire leads
• Housing and actuator color options
• LED or Neon illumination options
• Actuator marking options

• 19.2mm x 13mm panel cutout
• 15A, 125VAC; UL
• SPST or SPDT; latching or mom.
• QC-tabs, solder, PC pin, or wires
• Housing and actuator color options
• LED illumination options
• Actuator marking options

• SMT right angle;  IP67
• Silver – 3A, 120VAC or 28VDC; UL
• Gold – 0.4VA, 20V max. (AC or DC)
• SPDT; latching or momentary
• Standard, black rocker actuator
• Epoxy sealed terminals
• Tape & reel packaged

• Panel mount or through hole;  IP67
• Silver – 5A, 120VAC or 28VDC; UL
• Gold – 0.4VA, 20V max. (AC or DC)
• SPDT or DPDT; latching or mom.
• Straight, rt. angle, or rt. angle vert.
• PC Pin, solder, or quick-connect
• Rocker or paddle actuator style

• 16mm diameter panel cutout
• 0.4VA, 20V max. (AC or DC);  IP67
• SPST Off-(On)
• Solder termination
• Square bezel; round button flush
• Threaded bushing: M16 x 1.0
• Gold over silver contact material

• 13.6mm diameter panel cutout
• 100mA, 50VDC;  IP67
• SPST Off-(On)
• Solder termination
• Square button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

• 13.6mm diameter panel cutout
• 200mA, 50VDC;  IP67
• SPST Off-(On)
• Solder termination
• Square button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

• 13.6mm diameter panel cutout
• 200mA, 50VDC;  IP67
• SPST Off-(On)
• Solder termination
• Round button, many color options
• Threaded bushing: M12 x 0.75
• LED illumination options

• 36.5mm x 13.5mm panel cutout
• Up to 16A or 1HP, UL;  IP40 rated
• Panel mount snap-in
• DPDT; push-pull or momentary
• Pin plunger, or push-pull plunger
• Quick connect termination options
• Black or white body and actuator

• 28.4mm x 13.5mm panel cutout
• Up to 16A or 1HP, UL;  IP40 rated
• Panel mount snap-in
• SPDT; push-pull or momentary
• Pin plunger, or push-pull plunger
• Quick connect termination options
• Black or white body and actuator

• Through hole right angle
• 3A, 30VDC
• DPST; latching or momentary
• PC pin termination
• Plunger actuator, or Black Cap
• Cap option: 8.8mm Dia.
• Silver contact material

• Through hole
• 30mA, 28VDC
• SPST mom. or SPDT double action
• PC pin termination
• Firm tactile response
• High actuation force
• Non-illuminated

• SMT
• 20mA, 15VDC
• 4-way directional, center select
• Plunger for cap actuator
• Center: 500gf, Tilt: 280gf
• 12.4mm x 12.4mm body
• 12.2mm actuator height

• SMT
• 50mA, 12VDC
• 4-way directional, center select
• Plunger for cap actuator
• Center: 360gf, Tilt: 160gf
• 7.4mm x 7.7mm body
• Four actuator height options

• SMT
• 50mA, 12VDC
• 4-way directional, center select
• Tactile (5 Button) actuator
• Center: 320gf, Tilt: 180gf
• 9.8mm x 9.8mm body
• 1.55mm actuator height

• Through hole; right angle option
• 25mA, 24VDC
• Slide actuator; raised or recessed
• 1-12 positions; SPST each position
• 0.100″ (2.54mm) Full pitch
• Gold contact material
• Top tape seal option

• Through hole
• 25mA, 24VDC
• Piano actuator; raised or recessed
• 2-12 positions; SPST each position
• 0.100″ (2.54mm) Full pitch
• Gold contact material
• Top tape seal option

• SMT
• 25mA, 24VDC
• Slide actuator; recessed
• 2-10 positions; SPST each position
• 0.050″ (1.27mm) Half pitch
• Gold contact material
• Top tape seal option

• SMT
• 25mA, 24VDC
• Slide actuator; raised or recessed
• 1-10 positions; SPST each position
• 0.100″ (2.54mm) Full pitch
• Gold contact material
• Top tape seal option

• Through hole or SMT
• 25mA, 24VDC
• Slide actuator; raised or recessed
• 1-12 positions; SPST each position
• 0.100″ (2.54mm) Full pitch
• Gold contact material
• Top tape seal option

• Through hole or SMT
• 25mA, 24VDC
• Piano actuator; raised
• 2-10 positions; SPST each position
• 0.100″ (2.54mm) Full pitch
• Gold contact material

• SMT
• 1mA, 5VDC
• SPST Off-(On)
• Angled toggle detector
• 50gf max. force;  2.2mm travel
• Mounting boss option
• Ultraminiature size; guiding post

• 12mm diameter panel cutout;  IP40
• Up to 20A, 125VAC/30VDC, UL
• 1 or 2 pole; latching or momentary
• Solder, QC-tabs, screw, or wires
• Standard metal bat, or plastic bat
• 15/32-32 bushing
• -10°C to 125°C operating temp

• 12mm diameter panel cutout;  IP68
• Up to 20A, 125VAC/30VDC, UL
• 1 or 2 pole; latching or momentary
• Solder, QC-tabs, screw, or wires
• Standard metal bat, or plastic bat
• 15/32-32 bushing
• -10°C to 55°C operating temp

• 12mm diameter panel cutout
• Up to 24A, 125VAC, UL
• 3 pole; latching
• Solder, QC-tabs, screw, or wires
• Standard metal bat actuator
• M12 x 1.0 bushing
• 0°C to 85°C operating temp

• • 12mm diameter panel cutout
  • Up to 20A, 125VAC, UL
  • 2 pole; latching or momentary
  • Solder, QC-tabs, screw, or wires
  • Standard metal bat actuator
  • M12 x 1.0 or 15/32-32 bushing
  • 0°C to 85°C operating temp

• 12mm diameter panel cutout
• Up to 20A, 125VAC, UL
• 1 pole; latching or momentary
• Solder, QC-tabs, screw, or wires
• Standard or short metal bat
• M12 x 1.0 or 15/32-32 bushing
• 0°C to 85°C operating temp

• IP67
• SMT
• 4.60mm x 2.80mm
• 1.9mm or 2.5mm actuator height
• Three operating forces
• Up to 200,000 cycle life
• Silver contact material

• SMT
• 3.7mm x 3.7mm
• low profile of 0.35mm
• 0.15mm travel
• 160gf or 235 gf operating force
• Up to 500,000 cycle life
• Silver contact material

• SMT right angle
• 4.70mm x 3.50mm
• Gull wing termination
• Mounting boss option
• 160gf or 220gf
• Silver contact material
• 50mA @12VDC

• Panel mount or through hole
• 2A, 30VDC or 250VAC; UL
• SPDT On-On;  IP67 rated
• Solder, quick connect, or PC pin
• Pin plunger actuator
• 183gf max. operating force

• Panel mount
• 0.1A 48VDC or 125/250VAC; UL
• 3A 12VDC or 125/250VAC;  UL
• SPDT On-On;  IP67 rated
• Solder, or wire leads
• Pin plunger actuator
• 130gf max. operating force

• Chassis mount, or through hole
• 0.1A, 125VAC; UL
• 1A 24VDC; UL
• SPDT On-(On);  IP67 rated
• Solder, PC pin, or wire leads
• Pin plunger, or two lever options
• 50gf or 70gf operating force

• SMT
• 100mA, 125VAC or 48VDC
• SPST Off-(On)
• Pin plunger actuator
• 70gf operating force
• 3,000,000 life cycles
• Tape & reel packaged

• Thru hole or thru hole right angle
• 300mA, 6VDC
• SPDT On-(On)
• Lever actuator
• PC Pin right or left angle
• PC Pin long or short
• 20gf operating force

• Chassis, or thru hole rt angle
• Gold – 0.4VA, 20V max. (AC or DC)
• Silver – 15A, 125/250VAC; UL, VDE
• SPDT, SPST-NC, or SPST-NO
• Solder, quick connect, or PC pin
• Pin plunger, or six lever options
• 25gf – 250gf operating force

• SMT, thru hole, or rt. angle
• 300mA, 24VDC
• SPDT On-On
• Gullwing or PC pin options
• 250gf operating force
• 1.6mm travel
• Gold terminals

• SMT right angle
• 30mA, 15VDC
• SP3T On-On-(On)
• Gullwing termination
• 150gf operating force
• 1.5mm travel to any position
• 1.5mm height above pcb

• SMT right angle
• 25mA, 24VDC
• SPDT On-On
• Gullwing termination
• 150gf operating force
• 1.5mm travel
• 1.4mm height above pcb

• Panel mount or through hole
• <1A (dependent on model)
• Up to 6 poles
• Up to 6 actuator positions
• Vertical or right angle actuation
• Solder or PC pin
• Variety of package designs

• Panel mount, or through hole
• Gold- 0.4VA, 20V max. (AC or DC)
• Silver- 5A, 120VAC; 2A, 250VAC; UL
• SPDT or DPDT; 2 or 3 positions
• Vertical or right angle actuation
• Variety of termination options
• Epoxy sealed terminals

• Through hole
• 100mA, 16VDC
• SP9T – Single pole, 9 positions
• Shaft actuator; 9.8mm height
• 11.4mm x 12.4mm body
• Stainless steel cover
• Silver contact material

• 9.8mm or 10.2mm panel cutout
• 350mA, 125VAC
• 1-4 poles, 1-12 positions
• Flat, round, or slotted actuator
• Many actuator length options
• Non-shorting or shorting
• Standard or metric bushing

• 30mm x 22mm panel cutout
• Up to 20A, 125VAC; UL; IP55
• DPST or DPDT; latching or mom.
• Quick connect, or wire leads
• Housing and actuator color options
• Actuator marking options
• Non-illuminated

• 36.8mm x 21mm panel cutout
• Up to 20A, 125VAC; UL; IP54
• 1 or 2 pole; latching or mom.
• QC-tabs, solder, screw, or wires
• Housing and actuator color options
• Actuator marking options
• Matte or Glossy finish

• Four panel cutout options
• Up to 20A, 125VAC; UL; IP54
• SPST or SPDT; latching or mom.
• Quick connect, solder, or wires
• Housing and actuator color options
• LED illumination options
• Actuator marking options

• 19.2mm 6.8mm panel cutout
• Up to 16A, 125VAC; UL
• SPST Off-On
• Quick connect, or wire leads
• Housing and actuator color options
• Non-illuminated
• Actuator marking options

• 30mm 22mm panel cutout
• Up to 16A, 125VAC; UL; IP66
• DPST or DPDT; latching
• Quick connect, or wire leads
• Housing and actuator color options
• LED illumination options
• Actuator marking options

• 30.2mm 22mm panel cutout
• Up to 25A, 125VAC; UL
• DPST or DPDT; latching or mom.
• Quick connect, or wire leads
• Flat actuator
• LED illumination options
• Actuator marking options

• 30mm 22mm panel cutout
• Up to 20A, 125VAC; UL
• DPST or DPDT; latching or mom.
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-F02

• 30mm 11mm panel cutout
• Up to 20A, 125VAC; UL
• SPST or SPDT; latching or mom.
• Quick connect, or wire leads
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-F01

• 19.2mm 13mm panel cutout
• Up to 16A, 125VAC; UL
• SPST or DPST; Off-On
• Quick connect, PC pin, or wires
• LED illumination options
• Actuator marking options
• IP54 with PVC cap:  ACC-P01

• 37mm 21.2mm panel cutout
• Up to 20A, 125VAC; UL; IP67
• 1 or 2 pole; latching or mom.
• QC-tabs, solder, screw, or wires
• Many actuator style options
• LED illumination options
• Custom actuator marking avail.

• 19.2mm 6.65mm panel cutout
• 10A, 125VAC; UL
• SPST; latching or mom.
• Quick connect, or wire leads
• Housing and actuator color options
• Non-illuminated
• Actuator marking options

• Recessed magnetic, reed switch
• 500mA, 10V (AC/DC);  IP67 rated
• SPST Off-(On)
• 19mm or 25mm contact gap
• (2) 18 inch 22AWG wire leads
• Contact resistance: 150mΩ
• For position detection or sensing

Free hanging plug housing for ECM Series connector system with 3mm spacing, a low profile design, up to 10 poles, and 500mm wire leads option.

• 25mm panel cutout
• 3A, 250VAC, UL;  IP67 rated
• SPDT or DPDT; latching or mom.
• Flat actuator
• Solder, wire leads, or socket
• LED ring, ring/power, or graphic
• Stainless steel or black anodized

• 22mm panel cutout
• 3A, 250VAC, UL;  IP67 rated
• SPDT or DPDT; latching or mom.
• Flat actuator
• Solder, wire leads, or socket
• LED ring, ring/power, or graphic
• Stainless steel or black anodized

• 19mm panel cutout
• 3A, 250VAC, UL;  IP67 rated
• SPDT or DPDT; latching or mom.
• Flat actuator
• Solder, wire leads, or socket
• LED dot, ring, power, or graphic
• Nickel, stainless steel, or black

• 25mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST Off-(On)
• Short body design; flat actuator
• Solder or wire leads termination
• with ECM Connector option
• LED ring or ring/power symbol

• 22mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST Off-(On)
• Short body design; flat actuator
• Solder or wire leads termination
• with ECM Connector option
• LED ring or ring/power symbol

• 19mm panel cutout
• 2A, 36VDC;  IP67 rated
• SPST Off-(On)
• Short body design; flat actuator
• Solder or wire leads termination
• with ECM Connector option
• LED ring or ring/power symbol

• 25mm panel cutout
• 15A, 125VAC;  IP67 rated
• SPDT; latching or momentary
• Pre-mounted on LS Series switch
• Quick connect 0.187″ or wire leads
• LED ring, or ring/power symbol
• Stainless steel or black anodized

• 19m panel cutout
• 50mA, 24VDC;  IP65 rated
• SPST Off-(On)
• Tactile response; 0.5mm travel
• Solder or wire leads
• LED ring illumination
• Stainless steel or black anodized

• 22m panel cutout
• 2A, 24VDC;  IP65 rated
• SPDT or DPDT; latching or mom.
• Square bezel; flat actuator
• Solder or wire leads
• LED ring, or etched power symbol
• Stainless steel finish

• Socket extension for PV Series
• Solder or wire leads termination
• SPDT or DPDT
• LED illuminated, or non-illuminated
• Use with PV3, 4, 7, 8, 9, 10, or PVB3

• 19m panel cutout
• 20A, 250VAC, UL;  IP67 rated
• SPST; latching or momentary
• Flat actuator
• Solder or wire leads
• LED ring or ring/power symbol
• Stainless steel or black anodized

• 16m panel cutout
• 2A, 24VDC, UL;  IP67 rated
• SPDT; latching or momentary
• High or flat actuator
• Solder or wire leads
• LED ring or ring/power symbol
• Stainless steel or black anodized

• 16m panel cutout
• 2A, 36VDC;  IP67 rated
• SPST; latching or momentary
• Domed, high or flat bezel/actuator
• Solder, wire leads, or molded back
• LED ring or ring/power symbol
• Stainless steel, clear, or black

• 28m panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC or 4PST-2NO/2NC
• Flat actuator
• Solder or wire leads
• LED ring or dot
• Stainless steel or black anodized

• 25m panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC or 4PST-2NO/2NC
• Flat actuator
• Solder or wire leads
• LED ring, dot or power symbol
• Stainless steel or black anodized

• 22m panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC latching or mom.
• Flat actuator
• Solder or wire leads
• LED ring, dot or power symbol
• Stainless steel or black anodized

• 16mm panel cutout
• 2A, 48VDC;  IP65 rated
• SPST Off-(On) or Pilot Indicator
• High or flat actuator
• Solder or wire leads
• LED ring, dot, or power symbol
• Stainless steel, nickel or black

• 12mm panel cutout
• 2A, 36VDC;  IP65 rated
• SPST Off-(On)
• Domed or raised actuator
• Solder, screw, or wire leads
• Non-illuminated
• Body & actuator finish options

• 19mm panel cutout
• 2A, 24VDC;  IP67 rated*
• SPDT, DPDT, or DPDT-NO/NC
• High, or flat actuator
• Solder, screw, or wire leads
• LED ring, dot, or power symbol
• Stainless steel or black anodized

• 16mm panel cutout
• 2A, 48VDC;  IP67 or IP40 rated
• SPDT or DPDT; momentary
• Long or short body
• Guarded, high, or flat actuator
• Solder or wire leads
• LED ring or dot

• 16mm panel cutout
• 2A, 48VDC;  IP65 rated
• SPST Off-(On)
• Domed, high, or flat actuator
• Solder, screw, or wire leads
• Non-illuminated
• Gold, nickel, stainless, or black

• 40m panel cutout
• 2A, 48VDC;  IP65 rated
• DPST-NO/NC or 4PST-2NO/2NC
• Flat actuator
• Solder or wire leads
• LED ring or dot
• Stainless steel or black anodized

• 19mm panel cutout
• 2A, 36VDC;   IP65 rated
• SPST Off-(On)
• Domed, high, or flat actuator
• Solder, screw, or wire leads
• Non-illuminated
• Gold, nickel, stainless, or black

• 16mm panel cutout
• 2A, 24VDC;  IP67 rated
• SPST or SPDT; momentary
• Wire leads termination
• Actuator color options
• Non-illuminated
• Black nylon 6/6 housing

• 19mm or 22mm panel cutout
• 1A, 24VDC;  IP68 rated
• SPST; latching or momentary
• Touch sensor, capacitive switch
• Wire leads with connector
• LED ring, or ring/power symbol
• Aluminum, clear anodized finish
