Read MoreRB1 Series Illuminated, Power Rocker Switch with PVC Cap
RB1 Series Illuminated, Power Rocker Switch with PVC Cap
Stock Check for RB141C1000-135
Not the product you are looking for? Configure your product
ROCKER, 20A, 125VAC, SPST, Off-On, Panel Mount, Snap-In, Illuminated
About RB1 Series
- IP54 with PVC cap: ACC-F01-1
- 30mm x 11mm panel cutout
- Up to 20A, 125VAC, 3/4HP; UL, cUL
- SPST or SPDT; momentary or latching function
- Panel mount snap-in design
- Quick connect – 0.250″ termination
- Full illumination, dot illumination, or non-illuminated options
- Multiple housing and actuator color options
- Eight actuator marking options
- Many illumination color and voltage options
- -20°C to 65°C operating temperature
RB1 Series Markets
Product Specifications
RB141C1000-135
ROCKER, 20A, 125VAC, SPST, Off-On, Panel Mount, Snap-In, Illuminated
- Series Name RB1
- PackagingBulk
- Current Rating20A
- Voltage Rating125VAC
- CircuitSPST
- FunctionOff-On
- Mounting TypePanel Mount, Snap-In
- Termination TypeQuick Connect - 0.250"
- Actuator TypeConcave (Curved) - Illuminated
- Actuator ColorGreen
- Illumination StyleFull
- Illumination ColorLED, Green
- Illumination Voltage24VDC
- Ingress ProtectionIP54
- Panel Cutout DimensionsRectangular - 30mm x 11mm
- Operating Temperature-20°C to 105°C
Support for RB141C1000-135
Not the product you are looking for? Configure your product
