What Are Navigation Switches And What Are Their Uses?
December 5, 2023 | N/A min read
Some obvious examples of navigation switches can be found on gaming controllers, digital cameras or most consumer electronics that require...
Read MoreJS5208 Series 5-Position, Joystick Navigation Switch
JS5208 Series 5-Position, Joystick Navigation Switch
Stock Check for JS5208
Not the product you are looking for? Configure your product
NAVIGATION, 20mA , 15VDC, 5PST-NO, 4-Way Directional, Center Select, Surface Mount
About JS5208 Series
- 5-position, joystick navigation switch; 4-way directional, center select
- Surface mount (SMT) design
- Electrical rating: 20mA 15VDC
- 12.4mm x 12.4mm
- 12.2mm actuator height
- Gull wing termination
- Operating force: Center: 500gf ± 150gf; Tilt: 280gf ± 100gf
- 100,000 cycles mechanical life
- Travel: 8° ± 2° tilt; 1.0mm ± 0.2mm center
- Silver contact material
- -20°C to 70°C operating temperature
JS5208 Series Markets
Product Specifications
JS5208
NAVIGATION, 20mA , 15VDC, 5PST-NO, 4-Way Directional, Center Select, Surface Mount
- Series Name JS5208
- PackagingBulk
- Current Rating20mA
- Voltage Rating15VDC
- Circuit5PST-NO
- Function4-Way Directional, Center Select
- Mounting TypeSurface Mount
- Termination TypeGull Wing
- Contact MaterialSilver
- Actuator TypePlunger for Cap
- Actuator Height12.20mm
- Operating ForcePush: 500gf, Tilt: 280gf
- Operating Temperature-20°C to 70°C
- Nbr of Positions5
