EG Series Subminiature Slide Switch
Stock Check for EG1206A
Not the product you are looking for? Configure your product
SLIDE, 200mA, 30VDC, SPDT, On-On, Through Hole, Right Angle
About EG Series
- 200mA @ 30VDC
- Panel mount and PC board mounting designs
- Up to 6 poles; up to 6 actuator positions
- Vertical and horizontal actuation options
- 10,000 cycle life min.
- -20°C to 70°C operating temperature
- Please look at the data sheet to see the full range of slide switches available.
EG Series Markets
Product Specifications
EG1206A
SLIDE, 200mA, 30VDC, SPDT, On-On, Through Hole, Right Angle
- Series Name EG
- PackagingBulk
- Current Rating200mA
- Voltage Rating30VDC
- CircuitSPDT
- FunctionOn-On
- Mounting TypeThrough Hole, Right Angle
- Termination TypePC Pin
- Contact MaterialSilver
- Actuator TypeStandard
- Actuator Height6.00mm
- Illumination Style-
- Illumination Color-
- Operating Temperature-20°C to 70°C
- Contact TimingNon-Shorting (BBM)
