L16 Series Illuminated Pilot Indicator

L16 Series Illuminated Pilot Indicator

The L16 Series illuminated pilot indicators are panel mountable and come with square, rectangle, or round pushbutton heads. Neon, incandescent, and LED lamps are available, and lamp colors include red, green, yellow, or none. Applications for this switch include:

  • Lower power on/off designs
  • Telecommunications
  • Networking
  • Computers/servers
  • Performance audio
  • External hard drives and modems
  • Instrumentation

FEATURES

  • Circular, rectangular, and square panel mount designs
  • Signal light illumination with LED, neon, or incandescent lamps in multiple colors
  • Exclusively a pilot indicator light

CERTIFICATIONS

CATEGORIES

Series Configurator

* If you need further customization let us know and we'll see how we can help!

Product Number:

L16 Wire

* Product image not available for this configuration.

Displaying general product image that doesn't necessarily match configuration.

Detail Specifications

ELECTRICAL RATING: 8A @ 125 VAC [UL, CSA]; 6A @ 24 VDC [UL, CSA] MECHANICAL LIFE: 100,000 cycles ELECTRICAL LIFE: 50,000 cycles CONTACT RESISTANCE: 100mΩ max. typical; 2-4 VDC initial INSULATION RESISTANCE:  >1,000MΩ DIELECTRIC STRENGTH: >1,500 volts for 1 minute; >3,000 volts between poles ACTUATION FORCE: 300g/pole OPERATING/STORAGE TEMPERATURE: -25ºC to 55ºC
