800U Series CapsCaps for the 800U Series pushbutton switch -- the switch is ultraminiature in size, and sealed to IP67 ratings. pushbutton caps, miniature pushbutton caps, caps, pushbutton
The 800U series ultraminiature pushbutton switch caps can be ordered separately, as is shown here. You can create a part number in the configurator tab below.
You can order just the switch, or both the switch and the cap together, by clicking here and going to the configurator tab on that page.Other pushbutton switches
Other cap options switches
Configure your part number by selecting from the columns below.
When your part number is complete, click to view additional options.Additional Options
Round - 4.0mm dia.
Here are the specifications for the 800U series ultraminiature pushbutton switch:
ELECTRICAL RATING: 0.4VA @ 20V Max (AC or DC)
MECHANICAL LIFE: 40,000 Cycles
ELECTRICAL LIFE: 6,000 Cycles
CONTACT RESISTANCE: 100mΩ inital
INSULATION RESISTANCE: 500 MΩ Min.
DIELECTRIC STRENGTH: 500VAC
OPERATING/STORAGE TEMPERATURE: -30°C to 85°C
CONTACT ARRANGEMENT: SPDT, DPDT
ACTUATION FORCE: 250 gf
