E-Switch has been a leading electromechanical switch provider for nearly 50 years. We offer one of the broadest switch lines available today, and product offerings continue to expand monthly with new introductions that cater to almost any industry or market. Recent introductions include rocker, pushbutton, detector and anti-vandal switches, as well as connectors and socket extensions.
Customer demand and feedback is always incorporated into the latest E-Switch products, so you’ll want to keep up with the latest electronic switch news by keeping tabs on recent releases.
Latest E-Switch Catalog PDF
Electronic Switch News: E-Switch New Releases
January 2026: TL3220 Series Tactile Switch
- Surface mount (SMT) design
- Ultra-miniature 4.90mm x 4.90mm outline
- LED, RGB illumination
- Gull wing termination
- 100,000-cycle life
December 2025: LS25 Series Snap Action Switch
- High current electrical ratings:
- Silver – 25A, 125/250VAC; UL, cUL
- SPDT circuit; On-(Off) momentary function
- Ping plunger, lever, roller or simulated roller actuator
- 1,000,000-cycle mechanical life
- Operating Force: 90gf, 160gf, 180gf, 350gf or 400gf
November 2025: RP8700 Series Pushbutton Switch
- Full IP68 rating
- 13.6mm diameter panel cutout; threaded mount
- SPST; Off-(On) or On-(Off)
- Solder lug (3.5, 5.5 or 8.2mm high), PC through-hole or molded back with wired connector (300mm long)
- LED illumination potential; High cap (RP8701) or round cap (RP8702) options
October 2025: RCA1913 Series Rocker Switch
- Full IP68 both sides of panel
- 19.2mm x 13mm panel cutout
- Quick connect, solder, PC pin, PC pin right angle or wire leads (300mm)
- Electrical Ratings (UL and ENEC listed):
- 16(8)A, 125/250VAC
- 10(4)A, 125/250VAC
- 16A, 30VDC
- SPST or SPDT contacts; On-Off, On-On or On-Off-On functions
September 2025: RRS20 Series Rocker Switch
- IP68 rating from panel
- 20mm round panel cutout
- Quick connect, solder or wire leads (300mm)
- Electrical Ratings (UL and ENEC listed):
- 16(8)A, 125/250VAC
- 10(4)A, 125/250VAC
- 16A, 30VDC
- SPST or SPDT contacts; On-Off, On-On or On-Off-On functions
June 2025: KJE32 Series Pushbutton Switch
- Heavy duty design, industrial power
- Electromagnet provides automatic safety against power outages and restarts
- 46mm x 22mm x 2.5mm panel cutout
- Contact Ratings (TUV and UL listed):
- 20(20)A 250VAC
- 20(20)A 127VAC
- 25.1A 60VDC
- PVC cap for dust and water protection (IP55 rating)
May 2025: ECM Series Connector
- Free hanging 3mm spacing
- Wire-to-wire receptacle-to-plug system
- Low profile design
- Two to 10 poles
March 2025: PVPB3 Series Wired Socket Extension
- PVB3 Series socket extension with 22AWG, 140mm long wire leads
- IP67; 16mm diameter panel cutout
- Non-illuminated, LED or RGB illumination options
- UL recognized: 5A/250VAC (Resistive), 1.5A/250VAC (Inductive)
- SPDT; Momentary or Latching functions
February 2025: TD1260 Series Detector Switch
- Compact size
- Surface mount design
- SPST contact arrangement
- Sharp detection feeling
- J-Lead terminals
January 2025: PVHC7 Series Anti-Vandal Switch
- Electrical Rating: 20A @ 250VAC
- 22mm diameter panel cutout
- IP67 rated
- Non-illuminated, ring or ring/power symbol illumination with LED options
- SPST; latching or momentary function
- Stainless steel or black anodized body and actuator finish
November 2024: EGJ1210 Series Slide Switch
- Surface mount and through hole PC board design
- Right angle options
- 1.60mm travel
- Compact design
- 250 gram force to actuate
- SPDT function
September 2024: PZ3 Series Anti-Vandal (Piezo Switch)
- 16mm panel cutout
- IP68 (in-house tested)
- Electrical Rating: 1A, 5-24VDC
- Momentary Pulse Function
- 300mm wire leads with 1×2 connector housing pin
- Electrical Life: 50 million cycles
August 2024: TL1030 Series Tact Switch
- Surface mount design
- 3.5 x 2.9 mm size
- Operating force options: 160, 200, 350 and 500gf
- Up to 200,000-cycle life expectancy
- Operating/Storage Temperature: -40°C to +85°C
- Tape and Reel packaging (4,000 pcs/reel)
July 2024: PB350 Series Pushbutton Switch
- SPST or SPDT/Double action
- Double action: first circuit closes mid travel, second at full travel
- Long travel – 2.0mm
- High actuation force (ST: 490 grams; DT: 1st position – 600 grams, 2nd position – 1,150 grams)
- Tactile response
- LED colors: red, white, yellow, blue or green
