RA4 Series Illuminated, Power Rocker Switch with PVC Cap

RA4 Series Illuminated, Power Rocker Switch with PVC Cap

The RA4 Series illuminated, power rocker switch has curved and paddle actuator options and a PVC cap for dust and water protection. The switch provides ingress protection at an IP54 rating with the cap. Single- or double-pole circuits allow this LED rocker switch to perform maintained (latching) or momentary functions. Both the switch body and actuator is customizable, with multiple colors and marking options available for these custom rocker switches. The RA4 Series high current rocker switch is electrically rated for 16A of 125VAC at 1/3 HP T105 with cURus and UL agency approval. This custom rocker switch is meant for a panel mount cutout sized 22mm x 19.2mm.

FEATURES

  • Up to 16A, 125VAC, 1/3HP electrical rating
  • IP54 protection against dust and moisture with PVC cap
  • 22mm x 19.2mm panel cutout
  • 1 or 2 pole; maintained (latching) and momentary functions

RA4 Series Illuminated, Power Rocker Switch with PVC Cap

decoration Ra4 Wire

Industry Utilization:

CERTIFICATIONS

CATEGORIES

Series Configurator

* If you need further customization let us know and we'll see how we can help!

Product Number:

Ra4 Wire

* Product image not available for this configuration.

Displaying general product image that doesn't necessarily match configuration.

Most Common Configurations

RA41231121
RA41G31100

Detail Specifications

ELECTRICAL RATING: Option C: 16A @ 125VAC [UL, cUL]; 10A @ 250VAC [UL, cUL]; 1/3HP @ 125/250VAC, 105°C [UL, cUL]; Option 3: 10A @ 125VAC [UL, cUL] OPERATING TEMPERATURE: -20°C to 105°C [UL, cUL]            ELECTRICAL LIFE: 10,000 Cycles CONTACT RESISTANCE: 35mΩ Max. INSULATION RESISTANCE: 100MΩ Min. at 500VDC DIELECTRIC STRENGTH: 1,500VAC for 1 Minute DUST/MOISTURE PROTECTION: IP54 with PVC Cap
