Get Wired With E-Switch

Adding Wire Leads to a Switch Has Never Been Easier!

E-Switch offers several termination options that will enhance your production line and your bottom line. Selecting the right terminal option for your product assembly process will provide time and cost savings from:

  • No need to second-source wire leads and assembly house.
  • Reduce labor cost by ordering your switches pre-wired before arrival on your manufacturing floor.
  • Decrease product assembly time with the ease of installing behind the panel.

All of E-Switch’s panel mount switches are now available with wire leads. Whether you’re looking for an anti-vandal, keylock, rocker, pushbutton, snap action, slide or toggle switch for panel mounting, all are now available with wire leads.


View PDF Download PDF

The anti-vandal switch (a.k.a. vandal-resistant, vandal-proof, tamper-resistant or tamper-proof) was designed to be installed in devices and equipment that are susceptible to harsh use, vandalism, theft, as well as withstand extreme temperatures and be resistant to dust and moisture. The wired options are color-coded for convenience and are compatible with a variety of connectors.

Terminal Options:
Anti-vandal ULV Series

Anti-Vandal Series Solder Lug Terminal Option W
Wire Leads Attached
300mm Long		 Terminal Option M
Molded Protective Boot
with wire leads		 Terminal Option P
Detachable Socket
with wire leads
ULV4 Ulv4 Blue Dot Ulv4 W 188x113 150dpi 1 Ulv4f M 188x105 150dpi 1 Ulv4 2 1
ULV7 Ulv7 Transparent 1 Ulv7 W 188x110 150dpi 2 1 Ulv7 M 188x97 150dpi 1 Ulv7 1
ULV8 Ulv8 Green Ring 1 Ulv8 W 188x110 150dpi 1 Ulv8 M .188x105 150dpijpg 1 Ulv8 1



Terminal Options:
Anti-Vandal PV Series

Anti-Vandal Series Solder Lug Wire Leads Attached
300mm long		 PVP Detachable Socket
with Solder Lug		 PVP Detachable Socket
with Wire Leads
PV3 Pv3 Blue Dot 1 Pv3 Dw 1 Pv3socket.separate 1 Pv3 Socket 1
PV4 Pv4 Rgb Ss Ring Transp Bkgrd 1 Pv4 Dw Ss Blue Ring 1 Pv4socket 1 Pv4 Pvp Socket Wire Copy 1
PV7 Pv7 Ring Blue 1 Pv7 Dw 1 Pv7socket.separate 1 Pv7 With Wired Socket 1
PV8 Pv8 Ring Blue 1 Pv8 Dw Ring Color Blue 1 NA Image not available
PV9 Pv9 1 Pv9 Dw 1 NA Pv9 Socket Wired 1
PV10 Pv 10 Ring Color 1 Pv10 1 NA Pv10 Socket 1



Common Applications

Consumer Electronics, E-sports Gaming, Manufacturing Equipment, Lab Equipment Controls, Audio Visual Editing
